This Web Version
is being periodically updated
New: Appendix D on fuel cells, consistent use of fuel HHVs,
corrected theoretical yield of ethanol from starch, equivalent CO2
emissions and CExC adjusted to Patzek’s, not Shapouri et al.’s inputs,
added eroded soil humus oxidation
Increased ethanol yield to 2.5 gal/wet bushel, 91.5% of theoretical yield
Appendix E on free energy consumed to produce machinery
July 22, 2006
Contents
1 Introduction
1.1 Corn Highlights
1.2 Energy Inputs to Corn Production
1.3 Layout
3 Major Energy Inputs to Corn Production
3.1 Field Chemicals
3.1.1 Specific Energy Requirements for Nitrogen Fertilizer
3.1.2 Other Energy Inputs to Fertilizer Production
3.1.3 Specific Energy Requirements for Phosphorus Fertilizers
3.1.4 Specific Energy Requirements for Potassium Fertilizers
3.1.5 Specific Energy Requirements for Calcinated Lime
3.1.6 Specific Energy Requirements for Herbicides and Insecticides
3.2 Specific Energy Requirements for Fossil Fuels
3.3 Use of Electricity
3.4 Averages Can Be Misleading
3.5 Energy in Human Labor
3.6 Energy in Corn Seeds
3.7 Energy in Irrigation
3.8 Energy in Transportation
3.8.1 Personal Commute
3.9 Machinery & Infrastructure
3.10 Fossil Energy Inputs into Corn Production
3.11 Solar Energy Input into Corn Production
3.12 Soil Humus and Micro-Element Depletion by Corn Production
4 Major Energy Inputs to Ethanol Production
4.1 Corn Mass Balance Revisited
4.2 Transport in Ethanol Refineries
4.3 Fossil Energy Inputs to Ethanol
4.4 Energy Credits
4.5 Overall Energy Balance of the Corn-Ethanol Process
II Sustainability & Renewability
5 Thermodynamics and Economics
10 Sustainability
10.1 The Earth is an Open System to Heat Flow
10.2 Conclusions
III Sustainability of Corn-Ethanol Cycle
2 Available Free Energy
2.1 Introduction to Exergy
2.2 Change of Bth between Two States
2.3 An Industrial Flow Process
2.4 Cumulative Exergy Consumption (CExC)
3 The Ideal and Real Corn-Ethanol Cycle
5 The Carbon Cycle
5.1 Net CO2 Emissions
5.2 Conclusions
7 Exergy Analysis of the Ideal Corn Ethanol Cycle
7.1 Chemistry of the CO2-Glucose-EtOH Cycle
7.1.1 The Maximum Cycle Output per Unit Mass of Corn
8 Exergy Analysis of the Modified Ideal Corn-Ethanol Cycle
9 Resource Consumption and Waste Generation in the Industrial Corn-Ethanol Cycle
9.1 Cleanup of BOD in Ethanol Plant Wastewater
9.2 Cleanup of Contaminated Field Runoff Water
9.3 Restoration Work
IV Other Problems with Corn-Ethanol
2 First-Law View of Corn-Ethanol Production in 2004
3 Second-Law View of Corn-Ethanol Production in 2004
A Examples of Entropy Production and Disposal
B Availability and Irreversibility in Thermal Systems
C Is Economic Sustainability Possible?
D Efficiency of a Fuel Cell System
E Cumulative Exergy Consumption in Steel Production
E.1 Steel component manufacturing
List of Tables
1 Corn kernel composition
2 Application rates of field chemicals
3 Specific energies and application rates of nitrogen fertilizer
4 Energy consumption in superphosphate production
5 Specific energy and application rate of phosphorus fertilizers
6 Energy consumption in potassium fertilizer production
7 Specific energy and application rates of potassium fertilizer
8 Specific energy and application rates of calcinated lime
9 Specific energy and application rates of herbicides
10 Specific energy and application rates of insecticides
11 Average high and low heating values of fuels
12 Calorific values and specific volumes of gasoline
13 Calorific values and specific volumes of diesel fuel
14 Calorific values and specific volumes of LPG fuel
15 Calorific values and specific volumes of methane
16 Electricity use in corn farming
17 Energy used in transportation related to corn farming
18 Corn kernel composition
iv Thermodynamics of corn-ethanol biofuel
19 Specific CO2 emissions
20 Chemical exergies of compounds in the ideal corn-ethanol cycle
21 Product exergies after each step of the ideal corn-ethanol cycle
22 Product exergies after each step of the ideal corn-ethanol-hydrogen cycle
23 CExC of major non-renewable resources used in the industrial corn-ethanol cycle
24 First Law summary of the U.S. corn-ethanol production in 2004
25 Second Law summary of the U.S. corn-ethanol production in 2004
26 Primary energy consumption in steel production from ore
27 Primary energy consumption in steel production from scrap
28 Estimates of primary energy embedded in steel and its constituents
29 Estimates of CExC in steelmaking
List of Figures
1 Starch molecule
2 Mean ethanol yield
3 History of energy efficiency of ammonia production
4 Seven largest ammonia plants in the U.S.
5 Various estimates of the unit energy consumption to produce ammonium nitrate
6 The overall fertilizer application rates
7 The overall application rates of herbicides and insecticides
8 The overall fossil fuel volumes used in corn farming
9 By-state and average use of methane in corn farming
10 By-state and average use of electricity in corn farming
11 Energy use in labor
12 Specific energy use in transport related to corn farming
13 Major fossil energy inputs into corn farming
14 Solar energy dominates all other energy inputs to corn farming
15 soil nutrient losses with corn grain and stover removal
16 Mass balance of dry corn and efficiency of ethanol production
17 Average wet and dry corn yields
18 Average fossil energy inputs to ethanol production in a wet milling plant
19 The overall energy balance of ethanol production
20 Fossil energy gain/loss in corn ethanol production
21 Net energy yield in corn production
22 The boundary, process, and environment
23 The Second Law efficiency of copper production
24 The 2001 per capita energy consumption in the world
25 The 1990 per capita water consumption in the world
26 The 1999 per capita carbon emissions in the world
27 August 14, 2003, power blackout in New York
28 A linear process in industry
29 A linear process in industrial agriculture
30 Energy and mass flow in an ecosystem
31 Thermodynamic cycles
32 Exergy balance in an isothermal, ideal flow machine
33 Exergy balance in ideal and real nonisothermal industrial process
34 The ideal corn-ethanol cycle
35 Average U.S. corn yield from 1866 to 1939
36 The industrial corn-ethanol cycle
37 The carbon cycle
38 Specific CO2 emissions in the industrial corn-ethanol cycle
39 Total CO2 emissions in the industrial corn-ethanol cycle
40 The water cycle
41 Exergy flow the ideal CO2-Glucose-EtOH cycle
42 Exergy flow the ideal CO2-Glucose-EtOH-H2 cycle
43 Some of the useful work from the industrial corn-ethanol cycle is diverted to “undo” mining of the environment by this cycle
44 CExC by the industrial corn-ethanol cycle
45 The minimum cumulative exergy consumption by the industrial corn-ethanol cycle and its maximum useful work
46 Societal costs of ethanol production in the U.S.
47 The cumulative one-hour exceedances of maximum legal ozone level in Southern California
48 Electricity obtained from solar cells and ethanol powered fuel cells
Abstract
In this paper I define sustainability, sustainable cyclic processes, and quantify the degree of non-renewability of a major biofuel: ethanol produced from industrially-grown corn.
First, I demonstrate that more fossil energy is used to produce ethanol from corn than the ethanol’s calorific value. Analysis of the carbon cycle shows that all leftovers from ethanol production must be returned back to the fields to limit the irreversible mining of soil humus. Thus, production of ethanol from whole plants is unsustainable. In 2004, ethanol production from corn will generate 11 million tonnes of incremental CO2, over and above the amount of CO2 generated by burning gasoline with 115% of the calorific value of this ethanol.
Second, I calculate the cumulative exergy (available free energy) consumed in corn farming and ethanol production, and estimate the minimum amount of work necessary to restore the key non-renewable resources consumed by the industrial corn-ethanol cycle. This amount of work is compared with the maximum useful work obtained from the industrial corn-ethanol cycle. It appears that if the corn ethanol exergy is used to power a car engine, the minimum restoration work is about 7 times the maximum useful work from the cycle. This ratio drops down to 2.4, if an ideal (but nonexistent) fuel cell is used to process the ethanol.
Third, I estimate the U.S. taxpayer subsidies of the industrial corn-ethanol cycle at $3.3 billion in 2004. The parallel subsidies by the environment are estimated at $1.9 billion in 2004. The latter estimate will increase manifold when the restoration costs of aquifers, streams and rivers, and the Gulf of Mexico are also included.
Finally, I estimate that (per year and unit area) the inefficient solar cells produce 100 times more electricity than corn ethanol. We need to rely more on sunlight, the only source of renewable energy on the earth.
KEY WORDS: biofuel, ethanol, fossil fuels, corn, sustainability, thermodynamics, energy, entropy, exergy, solar
Nullis in verba (Take nobody’s word)
The motto of the Royal Society of London, 1662
1 Introduction
In the Preface to What is Life? – one of the great science classics of all times – Erwin Schrödinger (1967) observed: “A scientist is supposed to have a complete and thorough knowledge, at first hand, of some subjects and, therefore, is usually expected not to write on any topic of which he is not a master. This is regarded as a matter of noblesse oblige.”
The principle of non-interference with the far-away fields of science often precludes the scientists from seeking to explain the universal aspects of science, which are of paramount importance to the society at large. For example, the sophisticated technological models of biofuel production, e.g., Hemelinck (2004), cannot be formulated alone, without welding them first to a detailed analysis of the possibilities of depleting the environment in the long-term and destroying the valuable ecosystems1. This example is not merely of academic interest. A United Nations Bioenergy Primer (Kartha and Larson, 2000) states: “In the most biomass-intensive scenario, [modernized] biomass energy contributes…by 2050…about one half of total energy demand in developing countries. . . . The IPCC’s2 biomass intensive future energy supply scenario includes 385 million hectares of biomass energy plantations globally in 2050 (equivalent to about one quarter of current planted agricultural area), with three quarters of this area established in developing countries.” The magic word “sustainable” appears 130 times in this Primer, without ever being defined3. What will happen if the developing countries entrust their fragile ecosystems and societies to a fundamentally flawed, unsustainable energy supply scheme? What if the distributed generation of solar power is a significantly better alternative to biofuels?
So here I renounce the noblesse and embark on a synthesis of facts and theories related to the production of a common biofuel, ethanol from corn, albeit with second-hand knowledge of some of these facts – and at a risk of making a fool of myself. I hope that some or most of this paper will be read by the concerned farmers, engineers, environmentalists, and policymakers. In particular I wish to reach the fellow scientists, who – for most part – remain blissfully unaware of the astronomical real problems with supplying energy to over 6 billion people, but who often vigorously analyze the peripheral issues (which in addition are tackled in isolation and out of context).
Most traditional biofuels, such as ethanol from corn, wheat, or sugar beets, and biodiesel from oil seeds, are produced from classic agricultural food crops that require high-quality agricultural land for growth. A significant portion of the sunlight these crops capture is diverted to produce seeds and store sugar, and their growing seasons are short. The net energy yield of corn4, 100-130 GJ/ha-crop (Part I of this paper), is significantly lower that those5 of perennial crops and grasses (200-300 GJ/ha-crop), and sugarcane (400 GJ/ha-crop) (Rogner, 2000). Also, the environmental costs of annual crops are very high: they cause more soil erosion (up to 100-fold), require 7-10 times more pesticides, and more fertilizers than perennial grasses or wood (Berndes et al., 2003). Finally, industrial manufacturing of hybrid seeds is very energy-intensive.
In this paper, I will describe in some detail the unfavorable thermodynamics of the industrial production of ethanol from one particular food crop, corn. I will use the Second Law of thermodynamics to track what is happening to us (or, is it U.S.?) as mere years pass, and the precious resources the sun and the earth have been making and storing for millions of years are being squandered in front of our eyes.
1.1 Corn Highlights
The U.S. is the single largest corn producer in the world. Large overproduction of subsidized cheap corn forces corn producers and processors to invent new ingenious uses for their product6. In terms of their large negative impact on the society and the environment, two corn products – ethanol and high-fructose syrup – stand out (Pollan, 2002; Elliott et al., 2002). About 13% of the U.S. corn production is now diverted to produce ethanol. Hence, in this paper I will de facto argue that the U.S. corn production should be reduced by at least 13% with significant benefits to the taxpayers and the planet. A telegraphic description of the U.S. corn farming and processing is as follows:
- Corn is the single largest U.S. crop (a record 300 million tonnes of moist corn grain in 2004).
- Corn is harvested from 30 million hectares, roughly the area of Poland or Arizona, and a bit less than 1/4 of all harvested cropland in the U.S.
- The recent average yield7 of moist corn grain has been 8600 kg/ha (and a record 10100
kg/ha in 2004). - 42% of world’s 708 million tonnes of moist corn grain8 in 2004 was produced in U.S.
- All of the U.S. corn fields are fertilized.
- Corn requires more fertilizer than any other major crop; 40% of all nitrogen fertilizer goes to
corn (Frink et al., 1999). - Corn erodes soil much faster than it can rejuvenate by natural processes.
- Corn needs 100 cm water, 15% of corn is irrigated.
- Between 1995 and 2003, USDA distributed $37.4 billions, or $2 – $7 billions per year, in corn crop subsidies. Recipients of payments made through most cooperatives, and the amounts, have not been made public9.
- From 1995 to 2003, the top 10 percent of corn subsidy recipients were paid 68 percent of all corn subsidies. The mean payments were $465 172 each for the top first percent, and $176 415 each for the top tenth percent of recipients. The bottom 80% of farmers received mean payments of $4763 each.
- Over 12 billion liters of corn ethanol was produced in the U.S. in 2004.
- U.S. goal: Produce 20 billion liters of ethanol from corn annually.
- Ethanol producers receive $3 billion annually from the federal government and state governments, and extract $2 billion from the environment.
1.2 Energy Inputs to Corn Production
Fossil energy is essential to industrial agriculture. The following are the major energy inputs to industrial corn farming:
- Nitrogen fertilizers (all fossil energy)
- Phosphate, potash, and lime (mostly fossil energy)
- Herbicides and insecticides (all fossil energy)
- Fossil fuels: diesel, gasoline, liquified petroleum gas (LPG), and natural gas (NG)
- Electricity (almost all fossil energy)
- Transportation (all fossil energy)
- Corn seeds and irrigation (mostly fossil energy)
- Infrastructure (mostly fossil energy)
- Labor (mostly fossil energy)
Corn produced at a large expense of fossil energy is then transformed, with even more fossil energy, into pure ethanol.
1.3 Layout
This paper is divided into five parts, each of which can be read more-less independently. In Part I, I discuss the mass balance of corn processing, and the energy and mass balances of corn farming and ethanol production. Any First Law analysis of the corn-ethanol production process is fundamentally incomplete, and gives rise to confusion and arguments, which become moot once a more complete Second Law analysis is performed. Therefore, in Part II, I overview the fundamentals of thermodynamics, define the linear processes and cycles, irreversibility and sustainability, as well as exergy (the free energy available relative to the environmental conditions). In Part III, I apply the concepts developed in Part II to the industrial corn-ethanol cycle and answer the following questions:
1. Is ethanol production from corn a sustainable process?
2. If it is not sustainable, how unsustainable is it?
3. Can process changes result in making ethanol production from corn sustainable?
In particular, in Part III, I discuss the Carbon Cycle, the Water Cycle, the Ideal and Industrial Corn-Ethanol Cycles, and calculate the minimum work required to restore the nonrenewable resources consumed to produce corn ethanol. In Part IV, I estimate the various subsidies lavished on the transnational agribusiness corporations by the U.S. federal and local governments, and the huge subsidy extracted by these corporations from the U.S. environment: the rural population, soil, groundwater, rivers, the Gulf of Mexico, air, plants, and wildlife. Part V lists all major conclusions from this work. Through my analysis, I hope to put to rest the sweeping statements made by some scientists, such as the following (Deluga et al., 2004):
Fast and efficient fuel reforming is one of the critical steps in producing H2 for fuel cells and the “hydrogen economy,” and ethanol is now the most available and economically renewable fuel.. . . . . .Recent studies indicate that the energy in the fuel-ethanol is at least 1.34 times the energy used in its production.
Part I
Mass & Energy Balance
1 Introduction
Here, I revisit the classical story of ethanol from corn: the cumulative mass and energy balance of corn farming and subsequent ethanol production. There have been several well-known predecessors who told their versions of this story before. Professor David Pimentel of Cornell is the world-famous agricultural expert from Cornell University, author of the CRC Handbook of Energy Utilization in Agriculture (Pimentel, 1990), the book Food, Energy, and Society (Pimentel, 1996), and dozens of publications on the subjects of ethics and energy efficiency of agriculture, e.g., (Pimentel et al., 1988; Pimentel and Dazhong, 1990; Pimentel, 1991; Pimentel et al., 1994; Pimentel, 2001). Here I will use only his most recent analysis of production of corn-ethanol (Pimentel, 2003). Doctor Michael Wang, Christopher Saricks, and May Wu are the authors of the 1997 Argonne National Laboratory Report, Fuel-Cycle Fossil Energy Use and Greenhouse Gas Emissions of Fuel Ethanol Produced from the U.S. Midwestern Corn (Wang et al., 1997), which told quite a different version of the corn-ethanol story. Doctor Hosein Shapouri, James Duffield, and Michael Wang co-wrote the most recent 2002 USDA Report: The Energy Balance of Corn Ethanol: An Update (Shapouri et al., 2002a), which was less rosy than the Argonne Report, but considerably more optimistic than Professor Pimentel’s analysis. I joined the corn-ethanol story in late 2002, after reading the thought-provoking book, Food, Energy, and Society by Pimentel. Subsequently, in Spring 2003, I decided to teach a Freshman Seminar at Cal on the subject of corn ethanol, and published with the students our own version of the story, Ethanol from Corn: Clean Renewable Fuel for the Future, or Drain on Our Resources and Pockets? (?), highly critical of the Argonne Report, and also critical of the 2002 USDA Report.
The new twist in my current story is the consistent split of all energy flows into the specific energies in MJ/kg, and the mass fluxes in kg/ha-crop10. This split will make my explanations clearer, and the remaining errors easier to spot and correct. However nicely told, the classical ethanol-from-corn story is fundamentally incomplete and should be treated as Part I of the Ethanol Biofuel Trilogy. Parts II and III of this Trilogy must be told in the somewhat exotic language of the Second Law of thermodynamics, which describes the passage of Time and limits the possible directions of natural and industrial processes.
2 Mass Balance of Corn
Mass will be usually expressed in kilograms per hectare. One hectare is 10000 m2 or 2.47 acres.
It is safe to assume that the average corn yield in the U.S. has increased 5-fold over the last 70 years (NASS, 2004b). For example, in Indiana (Nielsen, 2002), the average corn yield was 3011 bushels per acre in 1930 and 156 bushels per acre in 2001. The steadily improving yield resulted mostly from the increased fertilizer use12 and better corn genetics.
In 2001-2003, corn in the U.S. was harvested from 28 × 106 hectares (NASS, 2004a). The average corn yield varied from 130 bushels per acre in 2002, to 138.2 bushels/acre in 2001, and 142.2 bushels/acre in 2003. (NASS, 2004a).
Definition 1 One equivalent bushel is defined as 56 pounds (25.4 kg) of corn grain that contains 15 percent of moisture by weight (Bender and Hill, 1997).
Therefore, the mean corn yield over the last 3 years was just below 8600 kg/ha of moist corn grain, or 8600 × 0.85 = 7300 kg/ha of dry corn grain.
Since ethanol (EtOH) is made from the hydrolyzed starch, see Figure 1, with the theoretical efficiency of 0.51, 1 kg of dry corn grain may yield (0.66×180/162) ×0.51 = 0.374 kg of water-free EtOH with zero losses, see Table 1. Therefore, from 1 hectare, one may theoretically produce 2730 kg EtOH, given the dry corn yield above. Of course there are losses in the corn-to-ethanol conversion process, and the practical efficiency will be lower.
Remark 1 In the U.S., the customary unit of reporting efficiency of corn conversion to ethanol is gallons EtOH per bushel, e.g., (Shapouri et al., 2002a). With the standard13 EtOH density of 0.787 kg/L of anhydrous EtOH at 250C, the theoretical efficiency of 0.374 kg EtOH/kg dry grain (0.475 L EtOH/kg dry grain) yields 3.19 gallons EtOH/dry bushel = 2.71 gallons EtOH/equivalent bushel of corn with 15% moisture14.
The 2000 − 2004 mean yield has been calculated as follows:
The factor of 0.95 accounts for 5% by volume of gasoline denaturant in the ethanol shipped from biorefineries.
Remark 2 The 2000-2004 mean ethanol yield in the U.S. is 2.477 2.5 gallons of pure EtOH (and up to 2% of longer-chain alcohols) per nominal wet bushel with 15% moisture. This yield has been calculated directly from the industry data. For details see (Patzek, 2006).
USDA has arrived at the volume-averaged estimate of 2.682 gallons of anhydrous ethanol per wet bushel (Shapouri et al., 2002b). This estimate is too high (Patzek, 2006), Section 3.
3 Major Energy Inputs to Corn Production
Most energy inputs will be expressed in MJ/kg of active ingredient in the input. For example, ammonia contains 82% nitrogen (active component); therefore, the specific energy input in MJ to obtain one kg of ammonia will be divided by 0.82.
3.1 Field Chemicals
• Nitrogen is a component of many important structural, genetic and metabolic compounds in plant cells. It is a major component of chlorophyll, amino acids, cell energy carriers (ATP/ADP), and genetic material (DNA/RNA).
• Phosphorus is one of the primary structural components of cell membranes. It is involved in the photosynthesis (ADP/ATP), synthesis of proteins and vitamins, and it occurs in important enzymes.
• Potassium activates enzymes that produce proteins and sugars. It maintains water content and, hence, the turgor (rigidity) of plant cells.
• Calcinated lime is used to increase the pH of soil acidified by nitrogen fertilizer. The ideal pH for corn is 6.6.
• Herbicides, such as Atrazine, Acetochlor, S-Metolachlor, Dicamba, Nicosulfuron, etc. are used to protect corn from weeds.
• Insecticides, such as Chlorpyrifos, Terbufos, Carbofuran, Tefluthrin, etc. are used to protect corn from insects.
The average application rates of major field chemicals used in corn farming are reported inTable 2.
3.1.1 Specific Energy Requirements for Nitrogen Fertilizer
Nitrogen fertilizers are derived from ammonia, nitric acid, and carbon dioxide. Practically all ammonia is produced from natural gas and nitrogen in the Haber-Bosch process (Worrell et al., 1994; Kongshaug, 1998; Worrell et al., 2000). The energy efficiency of the Haber-Bosch process has been improved by 1/3 over the last 60 years, see Figure 3. Therefore, the age of the ammoniaproducing plant does matter. Ernst Worrell et al. (2000) have compiled the ages and outputs of the 44 largest U.S. ammonia plants, see Figure 4. Most of these plants were built in the 1960’s, and some were later modernized and expanded. The fact is that the major U.S. plants were built 40 years ago, and some were revamped 20-30 years ago. Another example comes from Europe: In 1995, ammonia synthesis in modern European plants consumed approx. 36.93 MJ/kg N, while older plants needed about 43.08 MJ/kg N (Biermann et al., 1999).
Remark 3 For nitrogen fertilizer production, I will use the average efficiency of 30-year old plants. I will also assume that all nitrogen fertilizer applied to the U.S. corn fields is represented by ammonium nitrate.
Kongshaug (1998) analyzed energy efficiency of ammonia production and divided ammonia plants into three classes: “Modern,” “Average European plants,” and ”30-years old plants.” Using his terminology, the major nitrogen fertilizers are produced with the following specific energy inputs per unit mass of nitrogen in them.
Ammonia, NH3, has 82% of nitrogen by mass. Following Kongshaug (1998), I will assume the following net energy consumption to produce ammonia:
Average Europe
Modern
47
39
34.5
MJ/kg N
MJ/kg N
MJ/kg N
The November 1981 process description for Haldor Topsøe plants published in Hydrocarbon Processing (p. 129) gives 35.6 MJ/kg N as the total energy requirement for ammonia production.
According to Prof. Vaclav Smil (1985), total energy expanded on ammonia production in the U.S. is 55 MJ/kg N for the largest new plants, and up to 65 MJ/kg N for small pre-1969 units, the weighted average for all plants being 58 MJ/kg N (see p. 163-165). The European and Asian plants are more energy-efficient.
Urea, CO(NH2), has 45% of nitrogen by mass, and is obtained from ammonia and carbon dioxide: 2NH3+CO2 → CO(NH2)2+H2O. The net energy consumption (Kongshaug, 1998) is:
Smil’s (1985) estimate (p. 164) of the U.S. urea production costs is 70 MJ/kg N.
Ammonium Nitrate, NH4NO3, has 35% nitrogen by mass, and is produced from nitric acid and ammonia: HNO3+NH3 → NH4NO3. Nitric acid is obtained by burning ammonia over catalyst to produce NOx. One of the by-products of ammonium nitrate production is nitrous oxide N2O, a potent greenhouse gas. With 97% conversion of ammonia to AN, the energy consumption is
Smil’s (1985) estimate (p. 164) of the U.S. ammonium nitrate production costs is 72-90 MJ/kg N
3.1.2 Other Energy Inputs to Fertilizer Production
Primary particulation of fertilizers is carried out in prilling and granulation processes. The granulation units can also be used for a second pass of product building blocks (for mixed fertilizers), in addition to compaction and bulk blending units. The energy requirement for primary particulation is 0.25–0.5 MJ/kg product, and for secondary granulation and compaction 0.7-1.1 MJ/kg product (Kongshaug, 1998). Here I have used 0.5 MJ/kg of AN. The energy costs of natural gas recovery, compression, purification and transportation, and fertilizer packaging, if any, are estimated cautiously at 2 MJ/kg N. The various estimates of net energy inputs into nitrogen fertilizer production are shown in Figure 5 and listed in Table 3. In all the tables below, the estimates by Shapouri et al. come from their 2002 report (Shapouri et al., 2002a), by Wang et al. from (Wang et al., 1997), and by Berthiaume et al. from (Berthiaume et al., 2001). Since Berthiaume et al. have reported only the specific exergy consumption, I have used my energy consumption estimates to represent theirs. I have also corrected and/or amended the various estimates as noted below.
3.1.3 Specific Energy Requirements for Phosphorus Fertilizers
Phosphate and phosphoric acid are produced from the igneous fluorapatite Ca10(PO4)6(F,OH)2, and the sedimentary francolite Ca10M(PO4)6x(CO3)x(F,OH)2+x. For example, superphosphate may be produced as follows:
Calcium sulphate (gypsum) produced in reaction (5)1 may be precipitated as a dihydrate, using milder conditions, 26-32% P2O5 at 70-800C, or a hemihydrate, using 40-52% P2O5 at 90-1100C. Even though it demands more energy, the hemihydrate reaction is preferred because it optimizes use of sulfuric acid. The energy costs of gypsum disposal are omitted here.
Unlike the European Fertilizer Manufacturers Association (EFMA), which maintains an informative web site, the U.S. does not have clear statistics on the types of phosphorus (and other) fertilizers used. From the USGS and U.S. Census Bureau documents, e.g., (Jasinski, 2002) and references therein, it may be deduced that calcium phosphates (triple superphosphate and single superphosphate) dominate in the U.S., followed by Di-Ammonium Phosphate (DAP).
Just as with nitrogen fertilizers, phosphate fertilizers have different contents of active ingredient, here P2O5. For example, triple superphosphate is 46% P2O5, single superphosphate 18-20%, and di-ammonium phosphate 46%.
In this analysis, I will use the single superphosphate as the reference phosphorus fertilizer. The typical energy consumption for the 30 years old technology is given by Kongshaug (1998), see Table 4. In contrast to the energy input for nitrogen fertilizer, the data for phosphorus vary widely between 5.1 MJ/kg P2O5 and 26.4 MJ/kg P2O5 (Pimentel and Dazhong, 1990). EFMA uses 15.8 MJ/kg P2O5 (Biermann et al., 1999).
Using the data in Table 4, the typical U.S. energy consumption is 0.3+6.5 = 6.8 MJ/kg P2O5 as single superphosphate. The specific energy consumption for phosphorus and its application rates are listed in Table 5.
3.1.4 Specific Energy Requirements for Potassium Fertilizers
The energy requirements for potassium vary from 4.0 MJ/kg K2O (Mudahar and Hignett, 1982) to 13.7 MJ/kg K2O (Patyk and Reinhardt, 1997). EFMA uses 9.3 MJ/kg K2O (Biermann et al., 1999). The typical energy requirements to produce different potassium fertilizers are listed in Table 6. Here I will use the muriate of potash (MOP), or KCl, as the typical potassium fertilizer. Production of KCl is mainly carried out by shaft mining and beneficiation. The most energy efficient potash processes, based on a high quality sylvanite salt, require only 1.5 MJ/kg MOP (2.5 MJ/kg K2O). The energy consumption, however, varies a lot, and estimates up to 6 MJ/kg MOP are reported for mining of more mixed salts (Kongshaug, 1998). Here I will treat KCl as an admixture to a superphosphate fertilizer, and give it an identical energy consumption of 6.8 MJ/kg K2O. The specific energy inputs and application rates for the potassium fertilizers are listed in Table 7.
3.1.5 Specific Energy Requirements for Calcinated Lime
Lime must be added to de-acidify soil after heavy use of nitrogen fertilizers. Calcinated lime, CaO, is obtained from limestone and dolomites. The calcination process is energy-intensive, and generates one mole of CO2 per one mole of CaO. EFMA uses 2.97 MJ/kg CaO (Biermann et al., 1999), but here I will follow the Australian Academy of Sciences and assume that only 1.75 MJ/kg CaO is used to produce calcinated lime.
Lime application rate is not commonly reported by the USDA. The suggested application rate is 1.8 times the application rate of nitrogen (Tisdale et al., 1985), but there are reports of several times higher application rates, e.g., (Pimentel, 2003). The total application rates of nitrogen, phosphorus and potash fertilizers, as well as that of calcinated lime are shown in Figure 6.
3.1.6 Specific Energy Requirements for Herbicides and Insecticides
There are many active ingredients in commercial herbicides and insecticides, but all have very high specific energy requirements for their production. Here I have used the data collected in Table 5 in Shapouri et al.’s report (2002a).
The specific energy inputs and application rates of herbicides and insecticides are listed in Tables 9 and 10. The overall application rates of herbicides and insecticides are also shown in Figure 7.
3.2 Specific Energy Requirements for Fossil Fuels
A unit mass of a fossil fuel gives out a specific amount of heat (its calorific value) when burned. The Low Heating Value (LHV), or Net Calorific Value (NCV), of a fossil fuel assumes that combustion products contain the water of combustion as vapor. The heat contained in this water is not recovered. Outside of power stations and fuel cells, water remains as vapor after combustion. The High Heating Value (HHV), or Gross Calorific Value (GCV), assumes that combustion water is entirely condensed. The heat contained in this water is recovered. Pimentel (2003), Shapouri et al. (2002a) seem to use HHV for all fuels. Wang et al. (1997) give only the total amount of energy for each fossil fuel; therefore, their specific values are back-calculated for each fuel and agree with my estimates.
In prior work, I used the low heating values of fuels in combustion engines to perform the First Law energy balance calculations (Patzek, 2004; Patzek et al., 2005). More recently, however, I was swayed by Bossel (2003b) to use the high heating values. The reason is simple: Regardless of a machine (an internal combustion engine or a fuel cell) we use to burn a fuel, the fuel’s full energetic potential could be realized if we improved this machine. In other words, in determining sustainability, we check what possibly could be done, not what actually is done.
Remark 4 (Use of High Heating Values) From now on, the high heating values of all fuels will be used to determine whether a technological process is sustainable according to the First and Second Law of thermodynamics.
After deciding on a high heating value for each fossil fuel, one needs to find the standard values for “average” gasoline, diesel fuel, LPG, and natural gas. Finding consensus was more difficult than I expected. The International Energy Agency’s (IEA) standards up to the year 2000 are published in (IEA, 2000). IEA changed its standards for gasoline equivalent and diesel fuel equivalent in 2003. Finally, I decided to use the high heating values measured and compiled by Professor :Dietram Castorph et al. at the Technical University of Munich (Castorph et al., 1999), see Table 11. For reference, the standard densities of liquid fuels used in this work are: gasoline, 0.74 kg/L; diesel fuel, 0.84 kg/L; LPG, 0.58 kg/L; natural gas, 0.84 kg/sm3, and ethanol 0.79 kg/L. The calorific values and average volumes of fossil fuels used in corn farming are listed in Tables 12 – 15. The cumulative volumes of all fossil fuels are shown in Figure 8.
Notice that not all sources account for all five fossil fuels, especially for LPG and natural gas. Both LPG and natural gas are used for corn drying and as fuel to power water pumps in irrigation. Their uses vary greatly from one state to another, and from one season to another, see Figure 9.
3.3 Use of Electricity
The average electric energy spent on farming 1 hectare of corn is listed in Table 16. Shapouri et al. (2002a) have attempted to include the efficiency of fossil energy conversion into electricity in their estimates. I have not done it here in the energy balance, but will consider all the steps in free energy conversion in the exergy balance in Part III. The average and the state data are compared in Figure 10. As with natural gas, variability in electricity use is very large.
3.4 Averages Can Be Misleading. . .
- Depending on the weather, state-to-state (regional) and year-to-year (temporal) variations in the use of electricity, liquid petroleum gas, and methane can be extreme.
- Therefore, a single calculation of energy efficiency of corn production for all states and all years is insufficient for the generalizations readily made from such a calculation. In other words, in the same corn growing season, the energy balance of corn ethanol production may be highly unfavorable in one state, and only somewhat unfavorable in another one.
3.5 Energy in Human Labor
Average labor time is 6.2 hrs/ha per growth season (Pimentel, 2003). I will assume that a physical worker is on a 4000 kcal/day diet. The specific energy to sustain a worker is then
and it is negligible.
In my estimate, I have used Shapouri et al.’s (2002a) custom labor estimate plus the worker sustenance energy, see Figure 11.
3.6 Energy in Corn Seeds
The production of hybrid corn seeds is very energy intensive (Pimentel, 2004a). Two corn genotypes are needed. The pollen from one genotype is used, and the pollen from the other genotype must be prevented from pollinating the genotype from which the corn seed will be harvested. Because of all these manipulations, about 7 times more energy is required to produce hybrid seeds compared with the energy in the same mass of corn grain.
The following data have been used to estimate the specific energy requirements for corn seeds:
- The seed rate is 57,000 (Corn Belt) –74,000 (West) seeds per ha (White and Johnson, 2003), p. 255.
- The mean weight of 1000 corn seeds is 0.332 kg (White and Johnson, 2003), p. 202.
- The caloric value of corn grain with 13-15% moisture is 15-16 MJ/kg.
- The production of hybrid corn requires about 104 MJ/kg (Heichel, 2004).
Both Shapouri et al. (2002a), and Wang et al. (1997) ignored the hybrid seed energy, and assigned just the diesel fuel energy for planting the seeds. I have amended their calculations with the seed energy, based on their reported seed rates, and moved their estimates of diesel fuel use in corn planting to the fuel category.
3.7 Energy in Irrigation
Corn gets water mostly from rainfall, but some irrigation is generally required. In a dry season, the use of irrigation systems may increase substantially, as seen from the electricity use by state reported in Figure 10. I have made the following assumptions to estimate the energy cost of corn irrigation:
- Only 15% of crop is irrigated, USDA-NASS, 1997, (Pimentel, 2003).
- On average 8.1 cm of water is used per acre, USDA-NASS, 1997, (Pimentel, 2003).
- Water is pumped on average from the depth of 100 m.
- Pump efficiency, etc., is 0.75.
Then the specific energy requirement for irrigation is
I have lowered Pimentel’s 2003 estimate of irrigation energy to my estimate. Both Shapouri et al., and Wang et al. have buried the irrigation energy in their use of electricity and methane, so they account for the irrigation indirectly, for the particular mixture of states and weather they considered. Since I use Shapouri et al.’s estimates for the fossil fuels, I have not included the irrigation energy in my calculations.
3.8 Energy in Transportation
The specific energy use in transportation related to corn farming has been estimated by Wang et al. (Wang et al., 1997), see Table 17. The total energy use is about 720 kJ/kg of field chemicals (fertilizers, lime, fuel, etc.) transported into the field (400 MJ/ha-crop), plus personal commutes, see Figure 12. This estimate is sensitive to the number of commutes to and from the field by personnel using motor vehicles.
3.8.1 Personal Commute
At 6.2 hr/ha/crop of labor, 20 l/100km gasoline use, and a 30 km round trip, the energy cost of commuting is
Therefore a single commute nearly doubles the overall transportation energy costs. This issue should be investigated further.
3.9 Machinery & Infrastructure
Industrial agriculture requires heavy machinery (trucks, tractors, ploughs, cranes, railroad cars, airplanes, locomotives, barges, ships, etc.), which must be replaced periodically. Industrial agriculture also requires an extensive infrastructure with a large environmental footprint (spare parts, machine shops, machine manufacturing factories, access roads, railroad tracks, ports, silos, pumps, driers, electricity generators, air-conditioners, etc.). Industrial corn is the single largest crop in the U.S., and its share of this infrastructure should be highest. The energy inputs as hardware have been estimated in Appendix E at 68-168 MJ/kg of operational machinery, close to the 110 MJ/kg estimated by Pimentel (2003). The mass of hardware assigned by Pimentel to corn farming is 55 kg/ha. Note that this estimate includes only a tiny part of the huge infrastructure listed above. Both Shapouri et al. (2002a) and Wang et al. (1997) omit this input altogether, but I have not amended their calculations.
3.10 Fossil Energy Inputs into Corn Production
The specific fossil energy requirements in industrial corn farming are shown in Figure 13. A few comments are in order.
- The lowered Pimentel’s 2003 estimate of fossil fuel energy plus irrigation is identical with that of Shapouri et al.
- The lowered Pimentel’s 2003 estimate of nitrogen fertilizer energy is higher than the uncorrected one by Shapouri et al., which is too low. My estimate is in the middle.
- Pimentel’s 2003 lime application rate is twice those of everyone else’s. It reflects the 1997 USDA average.
- Pimentel’s 2003 transportation energy is higher than everyone else’s. It may reflect 1-2 more commutes/ha/crop.
- Shapouri and Wang et al. have underestimated the fossil energy in seeds and left out the machinery and infrastructure.
- I have added my seed energy estimate to their inputs, but left the machinery out.
- Berthiaume et al. (2001) have not included several of the energy inputs in corn farming, so their estimate is presented here only for comparison.
- The estimates of fossil energy inputs range from 19 GJ/ha (Wang) to 33 GJ/ha (Pimentel). My estimate is 28 GJ/ha.
- Wang et al.’s estimates are consistently too low. Shapouri et al.’s and my estimates are almost identical. The only significant difference is the inclusion of machinery into my estimates.
- The fossil energy use in corn farming is large and equivalent to 0.4 (Wang et al.) to 0.7 (Pimentel) metric tonne of gasoline per hectare and per crop.
- The average energy use in corn farming does not tell the whole story because of the very large variability of energy use by state, depending on the local weather conditions.
- All estimates, including mine, have had errors and/or omissions at one stage or another. I hope that by bringing the approaches of all authors into a common framework, most of the deficiencies of the prior analyses have been eliminated.
3.11 Solar Energy Input into Corn Production
The amount of solar energy that irradiates 1 average hectare of corn field in the U.S. during the growth season is gigantic, and it dwarfs all fossil energy inputs and the calorific value of the 8600 kg of corn grain harvested from this hectare, see Figure 14. In fact, during the 120-day growth season, roughly only 0.7% of the solar energy is converted by corn plants into biomass (Biermann et al., 1999). In contrast, solar cells can collect sunlight all year long, see Appendix C. On an annual basis, the solar efficiency of corn plants drops by a factor of 3, i.e., only 0.2% of the solar energy is captured by an average corn crop15. In summary, the solar energy does not limit corn production – soil, water, and the dissolved nutrients do. I will discuss this crucially important point later. Here it suffices to say that if the sun were the limiting factor, the Sahara desert would be the best place to grow corn (Georgescu-Roegen, 1971).
3.12 Soil Humus and Micro-Element Depletion by Corn Production
Because good soil quality sustains farming, one needs to account for the extraction by corn plants of soil humus and metals.
Definition 2 Humus is the soil component which develops over time by the decomposition of organic matter.
Soil humus is among the principal carbon pools on continents. One hectare of corn produces 8600 kg of corn grain, cf. Section 2, and 8600 kg of stalk, leaves and roots (Pimentel, 2004a). By scaling Michaud’s (1995) results to the average U.S. corn yield, I have estimated that about 2600 kg/ha-crop of soil humus is extracted by the corn monoculture grown on tilled soil. Similarly, I have calculated that decomposing all 8600 kg of plant parts returns about 2100 kg/ha of humus (4:1 ratio). Therefore, with the full decomposition of plant leftovers, corn depletes 500 kg/ha-crop of humus.
The net humus depletion of 500 kg/ha-crop could be replenished by returning to the field 2000 kg/ha of corn grain leftovers from ethanol production. Otherwise, industrial corn farming is also soil mining, in addition to being crude oil, natural gas, and coal mining. I will come back to this point when I discuss the energy credits for ethanol production assumed by Wang et al. and Shapouri et al..
Based on the information in Troeh & Thompson (1993), Prof. Pimentel (2004b) has calculated that only 1630 kg of humus would be added to the soil from the 8600 kg/ha of corn residues. On the other hand, he points out that with appropriate field practices16 and continuous use of synthetic fertilizers, it is possible to keep soil humus at a constant value. The 20-year study of conventional corn and soybean production system in Rodale, Pennsylvania, following Penn. State recommendations, confirms that the soil humus has remained relatively constant at about 1.7% of soil carbon over most of the 20 years. At Rodale, the application rate of synthetic nitrogen fertilizer has been 140 kg/ha; phosphorus and potassium have been applied too17.
Stanley A. Barber (1977) estimated that harvesting about 9000 kg/ha of corn grain removes 150 kg/ha of N and 30 kg/ha of P, see Figure 15. Currently farmers are applying 150 kg/ha of N and 50kg/ha of P. The additional 9500 kg/ha of corn stover contains 80 kg/ha of N and 10 kg/ha of P. Back in the 1930’s – 1940’s, with corn yields below 2000 kg/ha, only 10–20 kg/ha of N was harvested with the grain. However, nitrogen was also being lost by leaching, denitrification, and erosion. With soil erosion rates of 20 to 30 t/ha/yr, from 50 to 90 kg/ha of nitrogen were being lost by erosion alone. Since then, soil erosion rates in the U.S. corn fields have declined to 10 to 15 t/ha/yr. Soil erosion is deadly when it comes to nutrient and water loss (Larson, 1979; Lindstrom et al., 1979).
All corn plant parts, other than the starch in corn grain, should be decomposed and recycled to recover their N, P, K, C, Ca, Mg, Zn, B, Cu, Mn, etc., and diminish the degree of unsustainability of corn farming. However, most of the nitrogen and phosphorus and some other nutrients are translocated from vegetative plant parts to the developing grain later in the season. According to Figure 15, a corn crop harvested with no recycling removes more than 1.5 times as much nitrogen, 1.6 as much phosphorus, 4 times as much potassium, 13 times as much calcium and 6 times as much magnesium as when this crop is harvested for grain. Other estimates are even more unfavorable (Wheaton et al., 1993). Whole plant harvest also removes most of the soil metals essential to the well-being of corn plants. The need to recycle plant parts and limit soil erosion largely negates the now fashionable attempts to produce ethanol from whole corn plants by harvesting everything from the corn field, see e.g., (NREL, 2002; Sheehan et al., 2004). Every ecosystem on the earth is highly optimized to recycle almost all mass it generates; otherwise life would not persist.
4 Major Energy Inputs to Ethanol Production
Conversion of corn grain into 100% ethanol (EtOH) is a fossil energy-intensive process, which also generates significant gas emissions, as well as liquid and solid waste. Here I will consider only wet-milling of corn to convert it into glucose, which is subsequently fermented to industrial beer, and distilled to 96% ethanol. The final water removal is achieved in molecular sieves that exclude water, or by distillation with benzene, see Eq. (9). Fermentation is a slightly exothermic catalytic burning of aqueous glucose, in which 49% of its mass is converted to carbon dioxide gas. The main liquid reaction product, ethanol, retains most of the free energy of the glucose. Dry milling is energetically similar, and need not be considered.
4.1 Corn Mass Balance Revisited
In Section 2, I calculated the theoretical efficiency of corn conversion into ethanol, in which every step is 100% efficient. Here, in agreement with the USDA estimate (Shapouri et al., 2002b), I will assume that the conversion of corn grain into 100% ethanol incurs 8.5% losses18 by mass, see Figure 16.
Two important conclusions can be drawn from Figure 16:
- The average yield of anhydrous ethanol from corn is now 0.435 L EtOH/kg dry corn grain, or 2.914 gallons of EtOH per 56 lbs of dry corn grain (“dry bushel”), or 2.477 gallons of EtOH per nominal wet bushel with 15% moisture.
- The reported field corn yields must be multiplied by 0.85 to convert the harvested corn to water-free or “dry” corn, see Figure 17.
- In the literature, the USDA estimate of 2.682 gallons EtOH/bushel has been multiplied by the moist corn grain yields; this is incorrect and leads to an overestimation of the corn-ethanol yield by 8% (1/4 of the positive fossil energy balance claimed by USDA)
.
4.2 Transport in Ethanol Refineries
Transport of materials and people in-and-out of an ethanol plant requires energy, and there is some disagreement between Pimentel and Patzek on one hand, and Shapouri et al. and Wang et al. on the other. Here it suffices to state that
- Corn grain (8600 kg/ha) and fuel (e.g., 1200 kg/ha of coal) must be transported in.
- Ethanol (2200 kg/ha), gluten meal and feed (2600 kg/ha) must be transported out
- Workers must travel in-and-out.
- Both Shapouri et al. and Wang et al. seem to underestimate these transport costs by a factor of 3-4.
4.3 Fossil Energy Inputs to Ethanol
Because transportation is but a small fraction of the total energy outlay in ethanol production, there is little disagreement in the various estimates of the total energy used to produce ethanol from corn, which are all close to 15 MJ/L EtOH, see Table 18. This is easily seen when the total lengths of the bars in Figure 18 are compared19.
4.4 Energy Credits
Major disagreements surface when it comes to energy credits used by the different authors to offset the high energy cost of ethanol production. The idea is to somehow use the market or energy value of gluten meal and gluten feed, see Table 1, both by-products of wet milled corn, to offset the fossil energy used to produce ethanol. Gluten meal is a more valuable by-product, but it is 4 times less abundant than gluten feed. The key assumptions made by the different authors are as follows:
- Wang et al. (1997) assume an energy credit of 30% of all energy inputs into ethanol production.
- Shapouri et al. (2002a) assume an energy credit of 5.9 MJ/L of ethanol, justifying it as the replacement value of soybean meal with corn gluten feed and meal.
- Pimentel (2003; 2004a), assumes an energy credit of 1.9 MJ/L of ethanol, justifying it as the replacement value of distiller’s dried grain in dry milling, which is similar in composition to soybean meal (it contains 30% protein, 8% fat). Pimentel also argues that gluten feed does not replace soybean meal; in addition soybean plants fix nitrogen, and corn does not, so the replacement is really difficult to justify.
- I give ethanol zero energy credit, and want the ethanol refineries to bear the transportation and disposal costs of gluten feed and meal, as well as all other solid and liquid waste from ethanol production. Some of the environmental restoration costs will be included in the discussion of the carbon and water cycles in ethanol production from corn. In Section 3.12, I have already argued that all of the ethanol processing leftovers should be returned to the field to replenish soil humus and micro-elements.
4.5 Overall Energy Balance of the Corn-Ethanol Process
With the energy credits or without, ethanol production from corn is a fossil energy losing proposition, even if the energy costs of environmental damage are neglected, see Figures 19 and 20. In addition, the net energy20 gained from corn production is small, see Figure 21; several times lower than those of perennial grasses and sugarcane (Rogner, 2000). As I have demonstrated above, corn grain is not the sun’s gift to the producers of corn ethanol, but it is one of the fossil energy inputs. The calorific value of corn grain is therefore shown in Figure 19 to demonstrate that a large fraction of the energy inputs into ethanol production is dissipated on fermentation, distillation, and farming. The horizontal lines in the middle of each bar in Figure 19 denote the corrected ethanol yield, cf. Section 4.1, given the corn yields shown in Figure 17.
Remark 5 It appears that the high net energy yields of corn production – up to 200 GJ/ha-crop – reported in the literature, e.g., (Rogner, 2000), are unrealistic, and result from an incomplete thermodynamic analysis of industrial corn production.
learning the science
— CHRISTOPHER ESSEX and ROSS MCKITRICK
Taken by Storm, The Troubled Science,
Policy and Politics of Global Warming (BPR Publishers, 2002)
Part II
Sustainability & Renewability
1 Introduction
The following type of reasoning (Sheehan et al., 2004) is not uncommon in environmental literature:
More broadly, an informal check of Amazon.com, performed on August 16, 2003, revealed 4454 book titles containing the word “sustain.” In particular, there were 573 book titles with “sustain*” and “*culture”23.” The phrase sustainable development is firmly rooted in our consciousness. Therefore, one must ask the following question: Is sustainable anything possible in nature? In the economy? Also, how sustained are the processes deemed by some as “sustainable”?
Human nature, being what it is, destines us to choose a “truly great but brief, not a long and dull, career24” on the earth. After our eventual demise, the earth will be home to other less ambitious and impatient species. The name of the game, therefore, is to make the human presence on the earth as happy as possible, albeit not too short25. These two tasks require careful thought and delicate balance of human actions. No country has demonstrated an adequate implementation of either. In fact the opposite may be true. As the entropy on the earth increases, the actions of governments and societies resemble more and more episodic spasms, with ever less forethought and deliberation. The current hot button issues: the Hydrogen Economy, Ethanol from Corn, and the War on Terrorism are good examples.
2 Disclaimer
The next eight sections of this paper are punctuated with verbatim quotations from, and my digestion of the most important book I have read in decades: The Entropy and the Economic Process by Nicholas Georgescu-Roegen (1906-1994), who was a great twentieth century thinker, economist, mathematician, historian, and philosopher. The impact of this book on my thinking has been profound.
3 Preliminaries
In science we divide actuality into two slices: one representing the partial process determined by our interest, and the second, its environment, see Figure 22. These two parts are separated by an analytic26 boundary. The boundary has two attributes. The first separates the process from the environment at any time (we can call this attribute the interface, or the frontier ), and the second defines the duration of the process27. Often the terms process and environment are used interchangeably with system and surroundings. We may not describe a process by what happens inside or outside of it, but only by what crosses its boundary. Anything of interest crossing the boundary from the environment into the process is an input, and anything crossing the boundary in the opposite direction is an output. Solar energy is a typical example of only an input for any terrestrial process. The various materials abbreviated as “waste” are examples of only outputs.
4 Laws of Thermodynamics
The three empirical laws of Classical Thermodynamics28 were originated by Joule, Clausius, Thomson, Planck and Nernst, and are often formulated as follows:
First Law or the Energy Conservation Law (Joule, Clausius, Thomson)
- Energy can neither be created or destroyed;
- The energy of the universe remains constant; or
- You can’t win.
Second Law or the Entropy Law (Clausius)
- Without the compensating changes elsewhere, heat can flow only from a hotter to a colder body; or
- With passing chronological time, the entropy of the universe tends towards a maximum; or
- You can’t break even.
Third Law (Nernst and Planck)
- The entropy of any condensed substance, i.e., liquid or solid, has at zero absolute temperature the value zero; or
- Zero absolute temperature cannot be reached; or
- You have to stay in the game.
The story of Classical Thermodynamics is rather simple if we ignore the fine print. Energy comes in two qualities: (1) free or available, and (2) bound or dissipated. Free energy can be transformed into mechanical work29. Like heat, free energy dissipates itself, without any loss, into bound energy. The material universe, therefore, changes spontaneously in such a way that free energy is degraded. The final outcome is a state where all energy is dissipated, the Heat Death as it was called in the earliest thermodynamics30.
For some technical reasons, which need not bother us now, entropy was defined by the formula:
where ΔS is the entropy increment, δQ is the quantity of heat transferred from a hotter to a colder body, and T is the absolute temperature at which the transfer is made. The entropy increments are always determined in the direction of Time31, from the earlier to the later moment in Time. So, if chronological Time τ2 is later than another Time τ1, then the entropy of the universe (or another closed system) is
The Entropy Law is the simplest (and thus far the only) law known to science, by which the existence of true happening in nature is recognized. The Entropy Law defines the boundaries of what cannot happen, but does not prescribe entirely what can. This loophole resulted in life. All life32 feeds on an environment of low-to-moderate entropy (highly organized ecosystems33, such as shallow sea water, a river or lake, a jungle, etc.), and is extinguished when the entropy of the environment becomes too high (the degraded environment of sterile desert or chemically polluted water).
5 Thermodynamics and Economics
Classical thermodynamics and economics34 are thoroughly bonded. In fact, thermodynamics has been mostly a physical theory of economic value from its inception by Carnot. Just as physical life, our whole economic life feeds on low entropy, e.g., on grain, lumber, steel, copper, aluminum, cloth, computers, etc., all of which are highly organized structures. A slab of electrolytic aluminum is worth much more than the dispersed molecules of aluminum oxide, diffused so much as to be of no use to us.
In 1860 or so, William Stanley Jevons described the phenomenon of resource degradation and dilution as follows: “The expression “exhaustion of our coal mines,” states the subject in the briefest form, but is sure to convey erroneous notions to those who do not reflect upon the long series of changes in our industrial condition which must result from the gradual deepening of our coal mines and the increased price of fuel. Many persons perhaps entertain a vague notion that some day our coal seams will be found emptied to the bottom, and swept clean like a coal-cellar. Our fires and furnaces, they think, will then be suddenly extinguished, and cold and darkness will be left to reign over a depopulated country. It is almost needless to say, however, that our mines are literally inexhaustible. We cannot get to the bottom of them; and though we may some day have to pay dear for fuel, it will never be positively wanting35.” Today we may substitute “crude oil” or “natural gas” for “coal”, and Jevons’ statement will be as true36.
In particular, thermodynamics explains to us (while economics usually does not37) why land has economic value, as opposed to price. Even though land cannot be consumed, it derives its economic value from two physical facts: (1) land allows humans to catch the most vital form of low entropy – sunlight – and (2) the earth stopped making land in large quantities. Other physical and chemical characteristics of fertile land38 are scarce in a different sense: (1) the amount of low entropy in the soil is finite and it decreases39 continuously and irrevocably, and (2) a given amount of low entropy can be used only once.
A different example of irrevocably lost low entropy is given by mining copper ore and transforming it into pure metallic copper. A sheet of manufactured copper metal is made of: (1) copper ore, (2) other raw and processing materials, (3) electricity from fossil fuels, and (4) mechanical work. All these factors ultimately resolve into an orderly structure of primary materials (e.g., highly concentrated copper atoms in the ore, fuel, electricity), i.e., to environmental low entropy and nothing else. The free energy used in production to deliver mechanical work, or to heat the ore, is irrevocably lost.
We cannot bootleg any entropy40 by means of an ingenious process or device. Just like a Maxwell demon41, we have merely sorted the copper atoms from all others, but in order to achieve this end-result we have used up irrevocably a greater amount of low entropy than the difference between the entropy of the copper metal and that of the copper ore.
In view of Figure 23, it would be a great mistake to compare just the latter two entropies and exclaim: “Lo! Man has created low entropy from high!” (Georgescu-Roegen, 1971). This claim, in effect, is made by all those who say that copper can be manufactured sustainably. The copper scrap recycling programs are successful, only because scrap copper (and aluminum) consumes less free energy than any other way of reconstituting metallic copper42. Nevertheless, insofar as fossil energy is used, by recycling we only postpone the inevitable exhaustion of low entropy in the environment.
6 Economic Activity
Economists have a tendency to view the economic process as a closed system, while ignoring the continuous inflow of low entropy from the environment43. From a physical point of view, the economic process is entropic; it neither consumes nor creates mass or energy, but only transforms low entropy to high. To make things worse, the parallel entropy generation process in the environment is spontaneous, and goes on by itself without human intervention.
The material production process, in contrast, depends on the intervention of humans, who like the Maxwell demon, sort and direct environmental entropy according to the process rules44. This sorting activity is not a part of natural environmental processes and creates high entropy, i.e., waste, at a (much) faster rate than the biological life processes. From a purely material point of view, the economic process always transforms low entropy into waste. So what could be the justification for economic activity?
World Resources Institute, U.S. EIA.
As described by Georgescu-Roegen, the true output of an economic process is not merely waste, but the enjoyment of life. It is not a coincidence that the very country, which on July 4, 1776 declared: “We hold these truths to be self-evident, that all men are created equal, that they are endowed by their Creator with certain unalienable Rights, that among these are Life, Liberty and the pursuit of Happiness,” uses over twice as much free energy per capita than any other country on the earth, see Figures 24- 26. In general, abundant free energy equals enjoyment of life. The converse statement is as true in real life as it is in Logic, see Figure 27.
7 Agriculture
The following statement is made surprisingly often: “Properly used, [the plants on the earth] can by their reproductive powers supply us indefinitely with the food, the wood, and the other natural products we require.45” Even though the intensity of sunlight that reaches the earth has not changed appreciably over the human scale of Time, the apparent dominance of solar energy in agricultural production should not obscure the importance of the entropic soil degradation by continuous cultivation. Soil degradation can be severe over a human life span. Even the earliest farmers knew that manuring a soil does not remove its degradation, and to farm always meant to mine, in part, the soil. Clean water is necessary for agriculture. Water is inevitably polluted by agricultural waste; therefore, water too is mined.
It would be a mistake to believe that the practice of fertilizing soil can defeat the Entropy Law and transform food production into an everlasting process. Life feeds not only on sunlight but also on the low entropy of an ecosystem46.
With time, draft animals, oxen, buffalo and horse, were replaced by machines. A tractor is made of iron, other metals, oil and coal, and it feeds on oil. The natural manure fertilizer from farm animals was replaced by the chemical fertilizers manufactured from methane, coal, oil, iron, copper, and the earth minerals.
unable to leave the city. The New York Times, August 14, 2003.
The importance of this switch should be self-evident: the main source of low entropy feeding agriculture has been switched from the practically infinite solar energy to the very finite stock of minerals in the earth’s crust. Of course, this switch limits how long and how many people can be fed by the earth. It is no longer the practically unlimited stock of the energy in the sun that limits our survival, but the meager stock of natural minerals mined from the earth crust. If M is the accessible fraction47 of this stock, and r is the average rate of its use, then M = rt, where t is the corresponding duration of human civilization that depends on the crustal minerals. Depending on the mineral, and its rate of use, this time can be estimated as several tens of years (high quality crude oil), through many hundreds of years (coal), to thousands of years (uranium); so much for sustainable development.
8 Industrial Production
Every car or appliance produced today means fewer human lives in the future. Every styrofoam cup, cell phone or TV set in a landfill now means fewer resources and happy humans later. In industry, just as in agriculture, the price of technological progress has been a shift from the abundant source of low entropy – the sun –, to the earth’s mineral resources. Any time these resources are wasted, we shorten the survival time of humanity. Confronted in the distant future with exhaustion of mineral resources, mankind will be tempted to retrace its steps; however, in view of the Entropy Law, it is impossible. Human evolution is irrevocable and cannot be retraced.
Because of the Entropy Law, the large-scale industrial production of fossil fuels (e.g., ethanol) from the industrial plants manufactured (Kimbrell, 2003) by modern agriculture, will only hasten the depletion of mineral resources and the eventual demise of our civilization.
9 Waste
The ever-increasing rate of economic activity generates ever more chemical waste. For the earth as whole, this waste cannot be disposed of48. Unless we use more free energy to process it, toxic waste once produced is here to stay. This free energy can only be used once, and will always diminish our future standard of living. Waste cleanup, collection and recycling have begun to interfere with our life and pockets49, and are no longer hidden from our industrial civilization. The ever-accumulating garbage and the toxic by-products of agriculture and industry are the living proof of the Entropy Law in action.
The process of concentrating copper atoms, whose entropy efficiency is shown in Figure 23, is analogous to the process of fishing out the contaminant molecules dispersed in a huge volume of water and rock. The entropy efficiency of any contaminant cleanup process must be lower than that of the copper production process.
10 Sustainability
The opposite of as yet undefined sustainability is irreversibility, and I define it first after Max
Karl Ernst Ludwig Planck (1858-1947):
Definition 3 (Irreversibility) A process is irreversible if it can in no way be reversed, all other processes are reversible. It is impossible, even with the assistance of all agents in nature, to restore everywhere the exact initial state when the irreversible process has once taken place (Planck, 1926).
Corollary 1 From the definition above, a linear process that converts the low entropy of fossil fuels
into waste is irreversible and cannot be sustainable.
In a linear process, see Figure 28 and 29, a finite stock of fossil fuels is rapidly depleted and burned to serve as a collective heat source for all heat engines employed by our civilization,see Figure 31a. In addition, the atmosphere, which acts as a heat sink, becomes polluted bychemical waste from combustion (chemical entropy), as well as by waste heat (thermal entropy).The earth can only export thermal entropy through its atmosphere, see Appendix A. In additionto the atmosphere, the earth, which is the system in Appendix B, also accumulates chemicalentropy. As a result, the linear fossil fuel process accumulates chemical entropy in the earth andthe atmosphere, and irreversibly degrades our planet on a time scale of our civilization, measuredin hundreds of years.
In contrast, a cyclic ecosystem can be sustainable, see Figure 30. A natural cycle uses the sun as its source of energy and low entropy, and it expels only waste heat into the atmosphere and, ultimately, into the universe, see Figure 31b. Most importantly, all materials involved in an ecosystem are recycled, and when the natural cycle is completed, only waste heat, or thermal entropy is generated.
In order to discuss the existence and constraints on sustainability, I need first to define it.
Definition 4 (Sustainability) A cyclic process is sustainable if and only if
2. The environment on which this process feeds and to which it expels its waste is also sustained “forever.”
Corollary 2 A cyclic process, which is also “sustainable,” must not reject chemicals into the environment,i.e., its net mass production must be “close” to zero “forever.”
Corollary 3 A sustainable cyclic process must not reject heat into the environment at a rate that is too high for the earth to export this heat to the universe; otherwise, the environment properties will change.
10.1 The Earth is an Open System to Heat Flow
Attributes (1)-(2) of a sustainable cyclic process would be a thermodynamic contradiction if the earth were approximately a closed system with respect to the infrared radiation (heat). These two attributes would then make a sustainable process a perpetual machine of the second kind. Luckily for us, the earth can be treated as an open system with respect to visible and infrared light, and a sustainable cyclic process may generate thermal entropy at a rate per unit area of the earth surface (specific entropy rate or flux) which is no more than the average flux of entropy export from the earth to the universe, jE/S , calculated from Eq. (34) in Appendix A, minus the specific rate of entropy generation in the atmosphere due to export of the solar energy, calculated from Eq. (39) in Appendix A.
To quantify sustainability, I first assert that a cyclic process always converts all forms of entropy to thermal entropy. Thermal entropy is the ultimate waste from all “sustainable” cyclic processes on the earth, and it should be used for comparisons. Second, per unit area of the earth, we know that (1) the always positive specific rate of thermal entropy generation due to everything happening on the earth is σ > 0, (2) the rate of increase of the specific thermal entropy of the atmosphere due to all these happenings is σa > 0, and (3) the specific rate of thermal entropy generation due to the energy transport from the earth to the universe is σt > 0. Then, for cyclic processes, strong sustainability can be defined mathematically, see Appendix B, as
at every point on the earth, and at all times. Over an arbitrary time interval [τ1, τ2], we can write the global condition of sustainability of all cyclic processes on the earth as (Eq. (55) in Appendix B)
where SE(τ1, τ2) is the total thermal entropy exported by the earth over the time interval [τ1, τ2], and St is the corresponding thermal entropy generation in the atmosphere due to the solar energy export.
10.2 Conclusions
The immediate observations from the above discussion are:
• If the atmosphere dissipates more energy due to the increased greenhouse gas loading by human (and natural) activities (σt increases), there will be less room for all other human activities to remain sustainable. Stahl estimates, (1996), Table 1, the specific entropy generation rate in the atmosphere to be σt = 0.2 W/K-m2. So only 1 W/K-m2 of thermal entropy generation is left to all human and other natural activities, see Appendix A.
• Only energy generation directly from the sun, sun-driven wind, and water can be sustainable.
• Burning or extracting large quantities of wood or green matter requires chemical fertilization and cannot be sustainable to the extent that growing plants mines fossil fuels as well as low entropy from the soil, see Section 7.
• Industrial agriculture can never be sustainable because it relies on the irreversible burning and chemical transformations of fossil fuels, see Section 7
Thanks to its tenderness, its joys, and fears,
To me the meanest flower that blows can give
Thoughts that do often lie too deep for tears.
— WILLIAM WORDSWORTH
Intimations of Immortality from Recollections of Early Childhood (1803-1806)
In thermodynamics, you have to get to the point where you understand
what any damn fool means no matter what he says
— PROF. A. R. GORDON
(Lecture Notes, Department of Chemistry, University of Toronto)
Part III
Sustainability of Corn-Ethanol Cycle
1 Introduction
As pointed out in Part II, our standard of life is maintained by the exploitation of natural resources that have accumulated in the earth over millions of years. A natural resource whose chemical composition differs most from the dead states of the elements comprising it is most valuable.
This part is devoted to the life-cycle analysis of industrial corn and the ethanol biofuel produced from it. In my analysis, I will move along the trail charted in the brilliant, albeit incomplete, paper by three Canadian scientists, Richard Berthiaume, Christian Bouchard, and Marc A. Rosen (Berthiaume et al., 2001). There will be, however, important differences. I define the industrial corn-ethanol system differently, include more inputs (which are more carefully estimated), and do not require the carbon and water cycles to close.
2 Available Free Energy
For example, relative to a datum environment (T0 = 250° C, p0 = 1 atm), the quality of heat rejected by a process depends on temperature:
Gibbs, Guoy, Stodola, and Keenan’s available free energy, see Appendix B, is known in chemical and engineering thermodynamics as exergy, and is denoted with the symbol B. The concept of exergy and its cumulative consumption in an industrial process has been significantly advanced by the distinguished Polish thermodynamicist, Jan Szargut, a professor at the Chemical Engineering Department of my Alma Mater, the Silesian Technical University, Gliwice, Poland. His monograph, published in English with David R. Morris and Frank R. Steward in 1988 (Szargut et al., 1988) was based on two decades of development and industrial applications of lifecycle analysis. Today, this monograph is still the most comprehensive source of exergy concepts, data, and examples.
2.1 Introduction to Exergy
An easy to understand definition of exergy was proposed by Ludwig Riekert (1975).
Definition 5 Exergy, B, is equal to the shaft work or electrical energy necessary to produce a material in its specified state from materials common in the environment in a reversible way, heat being exchanged with the environment at constant temperature T0.
We distinguish the potential exergy, Bp, kinetic exergy, Bk, physical exergy Bph, and chemical exergy, Bch:
• Physical exergy, Bph is the work obtainable by a reversible physical process from its initial state (T, P) to the environment state (T0, p0).
• Chemical exergy, Bch, is the work obtained by taking a substance at the pressure and temperature of the environment to the state of thermodynamic equilibrium with the datum levels of components of the environment.
• Thermal exergy, Bth, is the sum of physical and chemical exergies:
2.2 Change of Bth between Two States
Consider an ideal (reversible) flow machine, see Figure 32. An exergy carrier with enthalpy H1, and entropy S1 enters the machine. After physical and/or chemical changes, the effluent has enthalpy H2, and entropy S2. Heat is transferred between the environment and the working fluid at the ambient temperature T0. The first and second law of thermodynamics are simply:
Physical exergy can be calculated immediately from Eq. (16)
2.3 An Industrial Flow Process
Consider now an industrial steady-state flow process, which can occur in a heat engine, corn field, or ethanol plant, see Figure 33. The input to this irreversible process is an exergy carrier with the enthalpy H1, and entropy S1. The process is also supplied with the quantity of heat Q1 from the source having temperature T1 > T0. The process effluent has enthalpy H2, and entropy S2. The rejected amount of heat Q0 is transferred to the environment. The useful outcome of the process can be mechanical work Wu or a chemical product having parameters Hu and Su.
The effect of irreversibility is studied by comparing the industrial process with a reversible process with the same inflow and outflow parameters, and the same amount of driving heat. The only difference between these two processes is the amount of heat rejected to the environment. For the reversible process this heat is Q0r, and for the irreversible one, it is Q0.
The first and second law balances for the two processes are:
The increased useful effect of the reversible process causes the amount of rejected heat to be smaller than that in the industrial process, Q0r < Q0. The sum of all entropy increases in the industrial process is
while that in the reversible process is
From Eqs. (19) and (20) it follows that
and we obtain
The left hand-side of Eq. (22) represents the difference of the useful thermal exergy in the reversible
and industrial process, δB. It therefore represents the exergy loss due to the irreversibility of the
industrial process under consideration. We have recovered, again, the famous Guoy-Stodola law,
also derived in Appendix B.
2.4 Cumulative Exergy Consumption (CExC)
All steps of a production process leading from natural resources taken from the environment to the final product result in exergy losses or exergy consumption.
Definition 6 (CExC) The cumulative exergy consumption (CExC) is the sum of the exergy of all natural resources in all the steps of a production process.
The problem of cumulative energy consumption (CEnC), discussed in Part I, is better known, but calculation of CExC is more informative because it accounts for the exergy of non-energetic raw materials (soil, water, air, minerals) extracted from the environment.
3 The Ideal and Real Corn-Ethanol Cycle
Ideally, see Figure 34, the corn-ethanol system and cycle consist of three parts: (1) Sustainable corn farming, (2) Sustainable ethanol production, and (3) Ethanol combustion to produce useful work.
The cycle is driven only by solar energy, and all its chemical by-products are fully recycled. Only the low quality heat is rejected by the ideal corn-ethanol cycle into the environment, and this heat is exported through the atmosphere into the universe. All carbon dioxide is recycled, and so is all water. This low-rate ideal cycle cannot deliver the massive quantities of ethanol fuel from (bi)-annual corn crops, see Figure 35.
Remark 6 Between 1866 and 1939 (NASS, 2004b), the average yield of corn in the U.S. hovered around 26 ± 3 bushels per acre, or 1600 kg/ha, 1/5 of the average yield today. I will assume that 1600 kg/ha is the almost sustained corn yield using manuring, composting, crop rotation, and other not quite sustainable field practices. Note that between 1906 and 1937, the average corn yield declined, most likely due to the progressing soil deterioration50 cf. Section 7.
Corollary 4 From Remark 6 it follows that without the fossil fuel-derived fertilizers, the corn produced today in the U.S. would require at 140−180 million hectares, close to the entire cropland area in the U.S (187 million hectares total, 122 million hectares harvested in 2002, U.S. Census). There would not be enough animals to manure the fields, and low entropy in the soil would be exhausted within some 30 years. The same conclusion follows (perhaps with a different time scale) for any other industrial source of biomass. In short, no biofuel derived from plants is sustainable.
Instead of relying on the current solar energy, we use the ancient solar energy in the form of fossil fuels to accelerate the ideal corn-ethanol cycle, see Figure 36. With the massive infusion of crude oil, natural gas, coal, and their products, as well as fertilizers, pesticides and herbicides, we greatly increase the corn yield and the rate of ethanol production, but we also produce massive amounts of chemical waste. In addition, we deplete soil by removing too much plant matter from the fields, and deplete groundwater whenever there is not enough rain. The industrial corn-ethanol cycle relies on the linear processes of mining fossil fuels, soil, water, and air, and in view of Part II, it cannot be sustainable. All published statements to the contrary, e.g., (Wang et al., 1997; Shapouri et al., 2002a; Deluga et al., 2004; Sheehan et al., 2004), and many others, are scientifically indefensible. Below, I will quantify just how unsustainable the industrial corn-ethanol cycle is.
4 System Boundary
As required by thermodynamics, see Figure 34, I define the system as the topsoil of the corn fields, the corn plants, the corn-processing ethanol refineries, and the ethanol-burning combustion engines. The system inputs are the manufactured hybrid corn seeds, solar energy, fossil fuels, field chemicals, earth minerals (muriate of potash, phosphates, calcinated lime, etc.), electricity, machines, air (oxygen and carbon dioxide), and the atmospheric, surface and subsurface water. The system outputs are heat, oxygen O2, carbon dioxide CO2, carbon monoxide CO, gaseous ammonia NH3, nitrogen oxides NOx, sulfur oxides SOx, methane CH4, water as liquid and vapor, and a multitude of organic and inorganic water, soil and air contaminants.
5 The Carbon Cycle
The simplified carbon cycle inside the industrial corn-ethanol cycle is depicted in Figure 37. Consistently with the discussion in Part I, I require that all organic carbon be returned from the ethanol refineries to the fields. Therefore, the internal carbon cycle is closed. The corn plants bind CO2 from the air, which is then released back into the atmosphere by burning the ethanol fuel produced by the cycle, and by decomposing the stalk, roots and leaves of corn plants, as well as all those parts of corn grain that were not used to produce the ethanol.
Remark 7 Most of the biomass must be returned to the field51 to preserve topsoil. This requirement puts severe restrictions of the various schemes of converting biomass (rice straw, corn straw, tree parts, whole plants, etc.) to biofuels.
5.1 Net CO2 Emissions
As shown in Figure 36, our corn field-ethanol plant-combustion engine system uses fossil fuels as inputs, and outputs their combustion products into the environment. Therefore the industrial corn-ethanol cycle generates extra CO2 and other greenhouse gases, which will all be translated into equivalent CO2 for simplicity.
The question now is as follows: Does the industrial corn-ethanol cycle generate more equivalent CO2 from its fossil fuel inputs than the gaseous emissions from replacing the cycle’s ethanol with gasoline, methane or diesel fuel? To make this comparison fair, I will account for the cumulative exergy consumption in production of the fossil fuels by adding another 15% to their calorific values, in agreement with Szargut et al. (1988) and Sheehan et al. (1998).
By asking and answering this question, I seek to dispel common misconceptions about the industrially-manufactured biofuels, best summarized by the following quotation:
EIA is right, but then the CO2 emissions associated with the consumption of non-renewable resources in the industrial ethanol-corn cycle should be added to the transportation gasoline consumption. The question now is: What is the net balance?
To answer this question, I will use the EIA and the European Fertilizer Manufactures’ Association (EFMA) data on the specific carbon dioxide emissions from the fossil fuel inputs into the industrial corn-ethanol cycle, see Table 19. These specific emissions, in kg of CO2 per MJ in a fossil fuel, will be multiplied by the respective energy input fluxes in MJ ha−1 crop−1, established in Part I. Electricity is treated differently, and its specific CO2 emissions account for the average U.S. efficiency of conversion of thermal energy into electricity.
To convert the NOx emissions from the industrial corn-ethanol cycle to the equivalent CO2 emissions, I will follow the guidelines of EIA (2002), the Intergovernmental Panel on Climate Change (IPCC) (1997), and EFMA (Biermann et al., 1999):
• 30% of applied N escapes from the field, and 2.5% of that quantity is converted to N2O in surface water.
• 10% of applied N escapes as NH3 into the air, and 1% of that becomes N2O.
• Nitrous oxide is 300 times more potent as a greenhouse gas (GHG) than CO2.
• An average ammonia plant emits 0.03 kg N2O/kg N in nitric acid, which is used to make ammonium nitrate.
The equivalent CO2 emissions from the fertilized corn fields are then 950 kg/ha. The equivalent CO2 emissions from the production of ammonium nitrate are 150×0.03×300×63/80 = ≈ 1000 kg/ha54.
The CO2 emissions resulting from electricity use in the removal of Biological Oxygen Demand (BOD) in wastewater from ethanol refineries, cf. Section 6, are also included.
In addition I have made the following assumptions:
(a) topsoil contains 4% of humus (Stevenson, 1982), (b) humus contains 50% of C by weight (Stevenson, 1982), wind-eroded soil is enriched in humus by (1.3 + 5)/2 3 on average (Allison, 1973), (c) wind erodes only 1 mm of topsoil per year, or 10 tonnes/ha-yr (Pimentel, 2006), and (d) the airborne humus is completely oxidized.
• To make the comparisons meaningful, methane, gasoline, and diesel fuel are now charged with incremental 17% (2% more than before) emissions for their recovery, transportation, and processing.
5.2 Conclusions
The results of my calculations, shown in Figures 38 and 39, lead to the following conclusions:
1. According to my estimates, 1 ha of industrial corn-for-ethanol generates 8955 kg of equivalent CO2 from the fossil fuel inputs and humus oxidation.
2. If the amount of gasoline with the energy content of 117% of 2498 kg EtOH/ha obtained on average from corn were burned, it would generate 5817 kg of CO2.
3. The net equivalent CO2 emissions are then 8955−5817 3100 kg/ha above those of gasoline.
4. Today, the industrial corn-ethanol cycle generates on 4.9 million hectares about 15.4 million metric tonnes of equivalent CO2/year over and above the energy-equivalent gasoline.
5. To satisfy 10% of U.S. fuel consumption, the additional equivalent CO2 emissions will be about 127 million metric tonnes per year.
6 Water Cycle
The water cycle can be idealized by bringing all necessary water to an imaginary “water tank”
at the top of Figure 40. The water is then dispensed from this tank as rain, irrigation water, and
ethanol plant feed water. Water is used by the corn plants, but it also evaporates from the fields,
runs off as contaminated surface water, and seeps back into the groundwater, contaminating the
underlying aquifers as well. Additional water is evaporated during drying of the harvested corn in
NG/LPG driers.
To estimate the average water requirement by corn plants, I will use Pimentel’s (2003) average
estimate of ≈100 cm of water per crop55. This translates into 10 × 106 L/ha-crop. About 15% of the water demand (USDA, 1998), 8.1 × 105 L/ha-crop, comes from pumping groundwater and surface water to irrigate corn. For comparison, the average water requirement by corn in Nebraska is 53-71 cm, and roughly 50% of corn acreage is irrigated there (Benham, 1998). Nebraska sits on top of the most prolific part of the giant High Plains aquifer (USGS, 2003; Rosenberg et al., 1999). Water mining from the High Plains aquifer continues in Texas, Kansas, Oklahoma, New Mexico and Colorado, while the water levels in Nebraska and Wyoming have stabilized or increased, see USGS (2003) and the references therein.
To estimate the water inputs into a wet-milling ethanol plant I will use the data published in the Corn Chemistry and Technology Handbook (White and Johnson, 2003) and by Pimentel (2003). According to White and Johnson (2003), one needs the following amounts of process water per 1 liter of ethanol:
• 20-25 liters in glucose fermentation (p. 697).
• The total amount is 30-37 liters of clean process water per 1 liter of ethanol, or 38-46 liters of water per kilogram of ethanol.
• The average 5-day biochemical oxygen demand (BOD) of waste water is 1000-2000 mg/L.
According to Pimentel (2003), 159 liters of water are needed to produce 1 liter of 95% ethanol, which translates to 190 liters of water per kg of 100% ethanol. Twelve liters of waste-water are generated per 1 liter of ethanol from the separation of industrial beer with 8 percent of ethanol by volume. The wastewater BOD is 18000-37000 mg/L, 10-20 times higher than the previous estimate. This estimate makes sense because the beer wastewater contains dead yeast and unreacted glucose. After mixing with cleaner process water, the overall BOD must go down. Berthiaume et al. (2001), erroneously use 160 L of wastewater per L of EtOH, with the BOD of 20000 mg/L.
For the time being, I will go along with 46 L water/kg EtOH with the BOD56 of 2000 mg/L. Thus, a wet milling ethanol plant needs on average
of water, and it generates 230 kg of BOD/ha-crop. This amount of process water is 100 times
smaller than the amount of water needed to grow corn in the field.
Remark 8 The industrial corn-ethanol cycle needs about 10 ×106 liters of water per hectare and per crop. This amount of water must be deposited in the tank. Depending on the weather and location, some or most of this water may have to come from mining an aquifer or surface water.
Since the volume of process water passing through the ethanol plant is two orders of magnitude smaller than that passing through the field, and all of the process water is readily accessible in holding tanks, ponds, etc., problems with cleaning it up are insignificant when compared with the field runoff water.
Remark 9 Industrial agriculture uses a huge land area, and it mines and contaminates huge amounts of soil, water, and air. The environmental damage it causes is much more widespread and more difficult to reign in than that from the highly-concentrated industrial sources. In addition, industrial agriculture invades and destroys large ecosystems. In other words, twenty-first century industrial agriculture poses a more acute threat to life on the earth, than the nineteenth century smoke stacks ever did57
7 Exergy Analysis of the Ideal Corn Ethanol Cycle
7.1 Chemistry of the CO2-Glucose-EtOH Cycle
The ideal the CO2-Glucose-EtOH cycle consists of three steps:
Step 1 Photosynthesis of glucose from atmospheric CO2:
Step 2 Production of ethanol from glucose:
Step 3 Combustion of ethanol:
The compounds that appear on both sides of the chemical reactions in Steps 2 and 3 do not participate in these reactions, but appear to close the cycle. The chemical exergies of all compounds are listed in Table 20. The chemical exergies of the products of each step of the cycle are listed in Table 21, and the exergy flow is depicted in Figure 41.
7.1.1 The Maximum Cycle Output per Unit Mass of Corn
To calculate the maximum possible energy output from the ideal CO2-Glucose-EtOH cycle, I made the following assumptions:
• Starch is converted into ≈100% ethanol with 0% losses.
• Corn delivered to an ethanol plant is 15% water.
• The net chemical exergy of an ideal ethanol cycle per kg of moist corn grain is
• At 8600 kg of moist corn per hectare58, the chemical exergy from an industrial ethanol cycle is
• With 91.5% overall conversion efficiency of starch into 100% ethanol, the chemical exergy is
Remark 10 The output of the industrial CO2-Glucose-EtOH cycle is the chemical exergy of ethanol equal to 77.1 GJ/ha-crop. This exergy can be transformed into useful work (e.g., shaft work or electricity) by different devices.
For example, the efficiency of an excellent internal combustion engine is 35% (usually it is 20%)
For fuel cell/electric motor vehicles the efficiency of conversion of chemical exergy to shaft work is higher. Suppose that we could reform ethanol to hydrogen, and use a fuel cell with 60% efficiency59 (Deluga et al., 2004)
to obtain electricity, and shaft work.
8 Exergy Analysis of the Modified Ideal Corn-Ethanol Cycle
Now let us look at the useful exergy production in the modified ideal corn-ethanol-hydrogen cycle
discussed by Deluga et al. (2004). This cycle is essentially the same as the cycle described in Eqs.
(24 – 26). The only difference is in Step 3, which is moderately endothermic, and lowers the cycle
efficiency by one percent, see Figure 42. The chemical exergies of the products of each step of the
modified cycle are listed in Table 22.
Step 3, reforming ethanol to hydrogen, is a catalytic variant of water-shift reaction:
Steps 3ab Ethanol oxidation to CO, and then Steps 3ab Ethanol oxidation to CO, and then CO2:
Note that Deluga et al. (2004) use a somewhat different stoichiometry with 10H2 and 10H2O, but this difference is insignificant.
Remark 11 The ideal CO2-Glucose-Ethanol-H2 cycle discussed in Deluga et al. (2004) produces practically the same amount of useful chemical exergy as the ideal CO2-Glucose-Ethanol cycle. Therefore, all conclusions pertinent to the latter hold for the former.
9 Resource Consumption and Waste Generation in the Industrial Corn-Ethanol Cycle
Now I will focus my attention on the industrial corn-ethanol cycle depicted in Figure 36. In contrast to the sun-driven ideal cycle, the industrial cycle relies heavily on fossil energy. Therefore, a part WR of the useful work Wu, must be diverted to restore the non-renewable resources depleted by the cycle, see Figure 43. As long as the useful work exceeds the restoration work, Wu > WR, theindustrial corn-ethanol cycle is beneficial, otherwise it is indefensible.
Remark 12 The depletion of concentrated natural resources is irrevocable, cf. Part II. Without causing changes in the environment, we cannot remanufacture the depleted amounts of oil, methane and coal in a reversible process, and put these fuels back into their deposits. Therefore, the reversible restoration work calculation provides the lowest estimate of the degree to which the irreversible industrial corn-ethanol cycle is also unsustainable.
From Definition 6, it follows directly that the minimum restoration work is equal to the sum of the cumulative exergy consumption (CExC) by all the processes that convert natural resources into inputs of the industrial corn-ethanol cycle.
The specific CExC for each such input is listed in Table 23. For example, the CExC by the production of ammonium nitrate starts from natural gas in the subsurface and nitrogen in the atmosphere, and continues by summing up all the intermediate steps. Even though the chemical exergy of ammonium nitrate is only 10.51 MJ/kgN, the cumulative exergy consumption to produce it is almost 10 times larger. The CExC by electricity generation is based on the average exergy efficiency of ten large modern power stations in the U.S. (Gill, 1984; Termuehlen and Emsperger, 2003).
Remark 13 Currently, the fossil fuels are mined from very concentrated deposits and upgraded in very large and efficient plants. Therefore, their CExC’s are relatively small. As the rich crude oil and natural gas deposits are depleted, in part to fuel extravagant and politically-driven projects such as corn-ethanol in the U.S., the CExC by gasoline, diesel fuel, and clean natural gas will increase dramatically. I will address this looming problem elsewhere.
The total CExC for each input is the product of the specific value in Table 23 (in MJ/kg) multiplied by the flux (in kg/ha-crop) estimated in Part I. The CExC by cleanup of the water contaminated in the industrial ethanol cycle was not yet considered, and will be discussed now.
9.1 Cleanup of BOD in Ethanol Plant Wastewater
The CExC by the cleanup of ethanol plant wastewater is the product of the total biological oxygen demand (BOD) in the wastewater stream in kg O2/ha-crop, and the specific CExC by BOD removal in MJ/kg O2. As discussed in Section 6, the total BOD is
After Berthiaume et al. (Berthiaume et al., 2001), I will base the specific CExC of BOD on a survey of energy consumption in municipal wastewater treatment facilities in the Canadian province of Queb´ec. According to Blais et al. (1995), an average electricity consumption of 4.13 kWh per kg of BOD removal was observed there.
I have used these estimates in the CO2 emission calculations shown in Figures 38 and 39.
9.2 Cleanup of Contaminated Field Runoff Water
Analysis of the cumulative exergy consumption in the cleanup of contaminated agricultural water that
• Runs off to streams, rivers, into the Mississippi River, and to the Gulf of Mexico, generating a large anoxic zone there,
is the subject of future research and will not be discussed here.
The Second Law of thermodynamics puts a high price on concentrating and removing dilute contamination, especially from the subsurface. Therefore the restoration work of cleaning up the field runoff water will be several orders of magnitude larger than that of the ethanol plant runoff water.
Better fertilization practices (Worrell et al., 1995), and artificial wetlands (Horne, 1991; Horne and Gregg, 1993; Horne et al., 1994; Horne, 1994) around the corn fields could significantly help in containing and removing the pervasive contamination these fields generate.
9.3 Restoration Work
Now we are ready to estimate the restoration work of the non-renewable resources mined by the industrial corn-ethanol cycle. The results for each major input are shown in Figure 44. The three main sources of exergy consumption are ethanol plant fuel, nitrogen fertilizer, and the removal of biological oxygen demand in the ethanol plant wastewater. Note that I have not yet included the potentially huge restoration work of the High Plains aquifer (which underlies many of the Corn Belt states), other aquifers, the numerous streams and rivers which drain the field wastewater, the Mississippi River, and the Gulf of Mexico at the Mississippi River mouth.
The bottom-line comparison is shown in Figure 45. Here I compare the as yet incomplete cumulative exergy consumption by the industrial corn-ethanol cycle with the cycle’s maximum
useful work performed by three different machines. This comparison reveals that the corn-ethanol
cycle consumes 2.3-7 times more exergy than it replaces.
The lowest deficiency of the cycle, by a factor of 2.3, is realized by employing an imaginary
60%-efficient Proton-Exchange Membrane (PEM) fuel cell to power a car. As shown in Appendix
D and elsewhere, such a cell simply cannot exist (Bossel, 2003b). Real fuel cells are 2-3 orders
more expensive than a car engine, 10 times less reliable, and may never be mass-produced (Keith
and Farrell, 2003; Dresselhaus et al., 2003; Bossel et al., 2003; Davis et al., 2002). A 35%-efficient
internal combustion engine produces 4 times less useful work than the restoration work, and today’s
average car engine produces 7 times less work. Note that if one uses the lowest advertised (but not
necessarily true) value of fossil fuel consumption to produce anhydrous ethanol, these factors are
2, 3, and 6 respectively.
Remark 14 No matter how efficient the engine is that transforms the industrial corn-ethanol
cycle’s output into shaft work, the cycle remains utterly unsustainable and unattractive as a source
of fossil fuel.
10 Conclusions
• This unfavorable ratio decreases to ≈4, when an efficient internal combustion engine is used to burn the ethanol, and to 2.3 when an imaginary hydrogen fuel cell is used.
• The industrial corn cycle is not renewable, and is unsustainable by a wide margin (at least 2.3 – 7 times).
• No process changes can make this cycle more viable.
• The annual corn-ethanol biofuel production is a human assault on geologic processes and the geologic time scale, and it can never work.
• The limiting factors, nutrient-rich humus and water that carries the dissolved nutrients to plant roots are augmented by chemicals obtained in the linear, irreversible fossil fuel-based processes.
• Over the last fifty years, corn yield has grown five-fold, mostly because of the steep increases in fertilization rate of corn fields.
• Sunlight is not a limiting factor, and could be used to great benefit if we were in less of a hurry, cf. Appendix C.
In vain, through every changeful year,
Did Nature lead him as before;
A primrose by a river’s brim
A yellow primrose was to him,
And it was nothing more.
— WILLIAM WORDSWORTH, Peter Bell (1819)
The outside world is something independent from man, something absolute, and the
quest for the laws which apply to this absolute appeared
to me as the most sublime scientific pursuit in life
— MAX PLANCK
Scientific Autobiography, and Other Papers (1949)
Part IV
Other Problems with Corn-Ethanol
1 Introduction
The results obtained in Part I and III can now be used to estimate the annual subsidies of the U.S. corn-ethanol biofuel. These subsidies fall into two categories: (1) the monetary subsidies by the U.S. Federal Government and State Governments to corn and ethanol producers, and (2) the non-monetary contributions of the U.S. population and environment polluted and mined by the industrial corn-ethanol cycle.
The first type of subsidy is easy to estimate:
• The federal excise taxes per gallon of fuel61: $0.184 for gasoline and $0.132 for EtOH-10 (10 vol% ethanol).
• Relative to gasoline, the federal tax breaks per 1 gallon of ethanol are
10 × ($0.184 − $0.132) = $0.52
• The state excise taxes per gallon of fuel vary widely and their volume-weighted average is difficult to estimate:
– EtOH-10 $0 in Arizona, up to $0.2535 in West Virginia
– Minnesota offers a $0.20 tax subsidy on EtOH-10. The state’s 13 ethanol refineries have received up to $3 million a year62.
• I will assume that the average state subsidy is only $0.10/gallon of ethanol. It is likely that the state subsidies of corn growers, ethanol producers, and EtOH-10 excise tax breaks are several times higher than my estimate.
The second type of subsidy can only be estimated by comparing the maximum useful output of the corn-ethanol cycle with the minimum restoration work necessary to undo the cycle’s negative impact on the environment.
2 First-Law View of Corn-Ethanol Production in 2004
In February 2004, the U.S. ethanol industry set an all-time monthly production record of 212,000 barrels per day (b/d) (12.3 GL/year), according to data released by the U.S. Energy Information Administration (EIA), the Renewable Fuels Association (RFA) reported. The previous all-time record was 211 000 b/d in the previous month. Production was up 25 percent compared to last February when 169 000 b/d (9.8 GL/year) of ethanol were produced.
“U.S. ethanol producers are doing everything they can to add much needed volume and octane to the U.S. gasoline market, thereby helping to hold down gasoline prices,” said RFA President Bob Dinneen. The ethanol industry is expected to produce more than 3.3 billion gallons in 2004, up from 2.81 billion gallons in 2003. Currently, 75 ethanol refineries have the capacity to produce more than 3.2 billion gallons annually. Thirteen additional plants under construction will add 500 million gallons of annual production capacity, RFA said.
The highlights of the U.S. corn-ethanol production in 2004 are listed in Table 24. Note that the 12.3 GL/yr of corn-ethanol replace only 9.2 GL/yr of gasoline equivalent (GE), and require 10.1 GL/yr of GE to produce. Corn-ethanol brings no energy savings and no lessening of the U.S. energy dependency on foreign crude oil, natural gas, and liquified petroleum gas. The opposite happens, we import more methane, LPG, and crude oil. We then burn these fuels to produce corn-ethanol and, finally, we burn the ethanol in our cars, causing extensive environmental damage at each stage of the industrial corn-ethanol cycle. Also note that the ethanol and corn tax-subsidies projected for 2004, will be 10 times higher than the total political contributions of Agribusiness over the last 14 years63.
3 Second-Law View of Corn-Ethanol Production in 2004
Second Law exergy analysis brings into the picture the significant contribution of the environment to corporate profits. Depending on which thermodynamic device transforms the chemical exergy of corn-ethanol into useful work, the difference between the minimum restoration work and the maximum useful work by the cycle will vary. This difference in GJ/ha, can be translated roughly into $/ha, and into the cumulative environmental cost of the industrial corn-ethanol cycle. The hidden cost of mining the environment by the industrial corn-ethanol cycle is real, but rarely mentioned. According to the RFA President Bob Dinneen, ethanol displaces imported crude oil. Therefore, to arrive at an estimate of corn-ethanol’s environmental costs, I assume that the total exergy deficit will be “paid” with the imported crude oil, whose price in the first half of 2004 was close to $35/barrel. I also assume that 1 barrel of oil is 136 kg of 350 API oil, with the specific energy content of 45 MJ/kg. The results are listed in Table 25.
In 2004, the environment has contributed an estimated 1.8 billion dollars per year by being continuously and irrevocably damaged and depleted. This huge gift to the corporate coffers from the U.S. rural population, soil, water, air, plants, and wildlife is as real as the federal tax subsidies. The 60%-efficient fuel cell car does not exist now, or in the future (Bossel, 2003b; Patzek and Pimentel, 2006). But even if in the next 20-years we were to replace all existing cars with efficient fuel cell cars, the environment’s contribution would still be $1.2 billion per year. If 10% of fuel consumption in the U.S. were supplied by corn-ethanol, the annual contribution from the environment would be $12 billion.
Again, my current estimate should be viewed as the lowest bound on the environmental costs for two reasons: (1) The true restoration work is irreversible and significantly larger than the reversible restoration work, and (2) I have not yet calculated the minimum reversible work of restoring surface and ground water, and soil contaminated by the corn field runoff water.
Source: Cal Hodge, President of A 2nd Opinion, Inc.
All the subsidies to corn growers, ethanol producers and distributors are compared in Figure 46.
4 Public Health Problems
The stated goal of adding ethanol from corn to gasoline was to help in cleaning the air we breathe
and lessen the U.S. dependence on foreign oil. The opposite is achieved. Air becomes more polluted,
and as much oil and more methane are burned as without the corn-ethanol. At the same time,
additional health hazards are created by the agricultural chemicals, fertilizers, insecticides and
herbicides, and by the waste water streams.
For example, in 2002, twelve Minnesota ethanol refineries agreed to spend $2 million per plant,
pay penalties of $29,000-$39,000, and limit the following air emissions64
• Carbon monoxide emissions by 2000 tons per year,
• Nitrogen oxides emissions by 180 tons per year,
• Particulate matter by 450 tons per year,
• Other hazardous air pollutants by 250 tons per year.
Ethanol-in-gasoline seriously pollutes the air (Hodge, 2002). The reactivity of the combined
exhaust and evaporative emissions using the ethanol-blended reformulated gasoline is estimated
to be about 17% larger than those using the MTBE-blended reformulated gasoline (NRC, 1999).
Ethanol does reduce the carbon monoxide emissions, but increases those of nitrogen oxides (NOx),
acetaldehyde, and peroxy-acetyl-nitrate (PAN) (Rice et al., 1999). The negative effects of using
gasoline-ethanol blends are clearly seen in Southern California, where ozone levels in the air exceeded
the one-hour legal limits more often, see Figure 47. By 2003, over 70% of gasoline produced
in Southern California was blended with ethanol.
In 2004, the California Air Quality Board completed a study (Hancock, 2005) in which the
fuel systems of several vehicles were tested for diurnal evaporative permeation emissions with fuels
containing MTBE and EtOH. The results were applied to the existing fleet in the South Coast
Air Basin and Sacramento. Their analysis showed a 17-ton-per-day (ton/d) increase in the South
Coast Air Basin on an ozone episodic day, an increase of 14% for evaporative emissions. For the
Sacramento Metropolitan area, the increase in evaporative emissions due to ethanol was estimated
to be 18% and 2.4 ton/d. In an earlier draft report, the California Air Quality Board concluded
(ARB, 2005) that in the South Coast Air Basin alone, the removal of ethanol oxygenate from
the reformulated gasoline CaRFG3 would decrease hydrocarbon emissions by 27.4 ton/d, NOx
emissions by 6.7 ton/d, and increase CO emissions by 1.4 tons/d. So much for the cleaner air. . .
div style=”float:right;text-align:right”
Friends, Romans, countrymen, lend me your ears;
I come to bury Cæsar, not to praise him.
The evil that men do lives after them;
The good is oft interred with their bones;
— WILLIAM SHAKESPEARE
Julius Cæsar Act 3, Scene 2,
(1599)
Part V
Summary & Conclusions
The purpose of this paper was to prove beyond any reasonable doubt that the industrial corn-ethanol cycle accelerates the irrevocable depletion of natural resources: fossil fuels, minerals, top soil, surface and subsurface water, and air, while creating wide-spread environmental damage throughout the continental United States. My arguments relied entirely on the First and Second Law of thermodynamics, and on the Law of Mass Conservation.
I have tried to avoid political questions, but at some point one should ask how it was possible for a poor agri-industrial technology to grow so explosively in the last four years? The only plausible answer lies in politics. The recent growth of ethanol production could occur only because of the massive transfer of money from the collective pocket of the U.S. taxpayers to the transnational agricultural cartel, represented most notably by Archer Daniel Midlands Co., Cargill Inc., Monsanto Co., and A. E. Stanley Manufacturing Co. This flow of billions of dollars from the pockets of the many to the pockets of the few was accomplished by federal subsidies of corn producers, and the federal and state tax subsidies of ethanol producers. It was spearheaded by many powerful, and I would like to think, thoroughly misinformed politicians.
More ominously, as a country, we have diverted our collective attention from the most important issue of this century: energy conservation and increased reliance on the only renewable source of energy, the sun, and its weak derivative, the wind, see Appendix C. Instead, we have somewhat accelerated the rate of depletion of the precious natural gas and crude oil deposits, in exchange for the significantly more wide-spread pollution of water, soil and air over roughly 1/2 of the area of the United States, the incremental carbon dioxide emissions, the substandard ethanol fuel, and the continuous drain of taxpayers’ money.
To make things worse, the scientific community in the U.S. seems to be preoccupied with promulgating empty illusions of a future global energy bliss brought about by the new and sexy, but inherently unsustainable technologies. The ethanol biofuel for hydrogen (Deluga et al., 2004), the fossil fuel-based “hydrogen economy” (Davis et al., 2002; Bossel et al., 2003; Dresselhaus et al., 2003; Keith and Farrell, 2003; Tromp et al., 2003; DOE, 2003), the subsurface carbon dioxide sequestration (Celia, 2002), etc., come to mind. I suggest that we – the scientists – should instead be advocating the simpler and less expensive, but painful, real solutions of the overwhelming energy problems facing the world. These solutions must involve far more energy conservation in every aspect of the U.S. economy, and the significantly increased reliance on the sun.
The philosophical, ethical, and political arguments ought to be developed further, but I will leave this task to the others, see e.g., the transcript of an excellent speech by Nicholas E. Hollis, Ethics and Agribusiness – In Search of the New Food Security, given in Newcastle-on-Tyne, United Kingdom, March 15, 2004. Here I will only reiterate the following:
2. The industrial corn-ethanol cycle generates more carbon-dioxide equivalents than would be generated by the energy-equivalent quantity of gasoline or diesel fuel penalized by 15% to account for the cumulative use of free energy in their production. Currently these incremental emissions are about 11 million tonnes of equivalent CO2 per year.
3. The taxpayers’ subsidies of the industrial corn-ethanol cycle are estimated at $3.5 billion in 2004. The parallel subsidies by the U.S. environment are estimated at $2.0 billion in 2004. The latter estimate will increase manifold when the restoration costs of aquifers, streams and rivers, and the Gulf of Mexico are also included.
4. The rate of sequestration of the unlimited solar energy as organic plant matter is controlled by the availability of water in soil and the minerals dissolved in this water. For the reasons explained in this paper, water and soil nutrients are finite, easily degradable, and must be replenished by decomposing all corn plant leftovers, including the byproducts of ethanol production.
5. The mass balance of starch in dry corn grain sets the theoretical efficiency of conversion of corn to ethanol to 0.374 kg EtOH/kg dry grain (0.475 L EtOH/kg dry grain), or to 3.19 gallons EtOH/dry bushel = 2.71 gallons EtOH/equivalent bushel of corn with 15% moisture.
6. A 4-year average of the ethanol industry reported yields is 2.477 gal EtOH/wet bushel, or 91.5% of the theoretical average.
7. Therefore, the commonly accepted USDA estimate of ethanol yield, 2.682 gallons EtOH/bushel (Shapouri et al., 2002b) is inconsistent with the industry data and too high.
8. All considered analyses of the fossil energy inputs into the industrial corn-ethanol cycle (Wang et al., 1997; Shapouri et al., 2002a; Pimentel, 2003; Berthiaume et al., 2001; Patzek et al., 2005) have been corrected and/or amended, as detailed in Part I.
9. With the corrected estimates of the fossil fuel inputs to corn farming and ethanol production, and using the high heating values of fossil fuels, three published estimates predict that production of corn-ethanol is the fossil energy losing proposition, and two show slight surpluses, see Figure 19. When the low heating values are used, all published analyses show that the corn ethanol’s calorific value is less than those of the fossil fuels (Patzek, 2004).
10. In view of Conclusion 4, the robust ≈30% energy credits for ethanol production used in (Wang et al., 1997; Shapouri et al., 2002a) are indefensible. In Part II, the Second Law analysis of the industrial corn-ethanol cycle reaffirms this conclusion.
11. The mere energy balance of the industrial corn-ethanol cycle does not take into account the cumulative consumption of the non-fossil environmental resources: soil, water, air and minerals, and provides an incomplete picture of this cycle.
12. Because all published First Law balances of the industrial corn-ethanol cycle have been incomplete by definition, their comparison has led to different interpretations, and endless acrimonious debate, see e.g., (Patzek et al., 2005), which served little useful purpose. Worse yet, this debate has diverted our collective attention from the real problems with corn-ethanol and provided cover for the ethanol lobby.
13. Only when the Second Law of thermodynamics and the concept of available free energy, or exergy, are introduced (Parts II and III, Appendix A and B), a definitive analysis of the industrial corn-ethanol cycle is possible.
14. In the Second Law analysis, the environment is defined as anything but the top soil of the corn field, the corn plants, the ethanol-producing plants, and the devices that process the ethanol (internal combustion engines and fuel cells). The environment, therefore, is the sun, water, air, nutrients, crude oil, methane, coal, electricity, field chemicals, roads, trucks, etc., and the cold universe to which the heat generated by the cycle’s ethanol is rejected. Thus, the environment defined here cannot be dismissed summarily as the raving of a green lunatic.
15. From the definitions of irreversibility and sustainability (Part II, Appendix A and B), it follows clearly that the industrial corn-ethanol cycle, which relies heavily on mining the environment, is irrevocable and unsustainable. The common references to the cycle sustainability, see, e.g., (Deluga et al., 2004), are scientifically indefensible.
16. In view of Conclusion 4, the recently-advertised ethanol production from “agricultural waste,” i.e., from plant leaves, stems, and roots is even more unsustainable.
17. Because the industrial corn-ethanol cycle is irrevocable, the precious natural resources wasted by it disappear forever from the earth, and diminish the wellbeing of future generations.
18. The free energy available on the earth (exergy) is consumed by the industrial corn-ethanol cycle. The cumulative net consumption of the exergy is a good quantitative indicator of the degree of unsustainability of this cycle.
19. The maximum useful free energy generated by the industrial cycle, 77.1 GJ/ha as cornethanol, produces useful shaft work, electricity, or both.
20. When an average car engine (20% efficiency) burns corn-ethanol, it produces 15.4 GJ/ha of useful work. A very efficient car engine (35% efficiency) produces 27.0 GJ/ha of useful work. An imaginary fuel cell/electric motor car with 60% efficiency, produces 46.3 GJ/ha of useful work (see Appendix D).
21. The maximum useful work from the industrial corn-ethanol cycle has been compared with the minimum reversible work required to undo the environmental damage caused by this cycle. Of course, this environmental damage cannot be undone in reality, and the minimum reversible restoration work is only a tool used to quantify the damage.
22. The cumulative exergy consumption in performing the minimum reversible work of “undoing” the industrial corn-ethanol cycle, exceeds by a factor 7, 4 and 2.3, respectively, the maximum useful work from a 20%-efficient car engine, 35%-efficient car engine, and a nonexistent 60%- efficient fuel cell car.
23. No process change can improve the very unfavorable ratio of benefits from the industrial corn ethanol cycle to its environmental costs, and I have not yet included the exponentially growing costs of restoring surface and ground water, and soil contaminated by the fertilizer-, pesticide- and insecticide-rich runoff from the corn fields.
24. More attention should be devoted to harvesting the only renewable source of energy on the earth: sunlight. An inefficient solar cell that continuously operates at moderate latitude produces ≈100 times more electricity than a corn ethanol-burning fuel cell (see Appendix C). Somewhat better, more durable and cheaper solar cells that are distributed worldwide would dramatically increase the chances of long-term survival of our civilization.
25. One hectare of solar cells placed anywhere can free 100 hectares of fertile agricultural land from industrial corn, and allow for the low-intensity, diversified, and almost sustainable agriculture.
offences contrary to the doctrine which ye have learned; and avoid them.
18 For they that are such serve not our Lord Jesus Christ, but their own belly;
and by good words and fair speeches deceive the hearts of the simple.
— THE EPISTLE OF PAUL THE APOSTLE TO THE ROMANS,
(The New Testament)
Acknowledgements
More than 60% of the work presented in this paper was performed at TU Delft, where I was a Visiting Professor at the Earth Sciences Department between February and June 2004. I would like to thank Prof. Jan-Dirk Jansen for hosting me and arranging financial support from TU Delft. I thank the bright and intellectually engaged Freshman Students at U.C. Berkeley, who attended my Freshman Seminars in Spring and Fall 2003, and greatly contributed to the ideas presented here. I thank Prof. David Pimentel of Cornell for patiently answering my endless questions, critique of my arguments, reviews of the evolving manuscript, and kind words of encouragement. I thank Prof. Clayton J. Radke of U.C. Berkeley for his critique of the early versions of the manuscript and suggestions of numerous improvements. Prof. Radke’s persistent skepticism has sharpened my arguments immeasurably. I also thank my son Lucas J. Patzek, a biochemistry senior at U.C. Santa Cruz, for meticulously correcting and improving the manuscript, as well as mitigating many of my statements.
Subsequent to the CRPS article publication, Dr. Drew Ronneberg of Technology and Management Services, Inc. has pointed out my error in calculating the theoretical efficiency of ethanol production from corn, kindly provided me with additional information about corn ethanol refineries, and highlighted the incompleteness of Jevons’ arguments about coal production.
A Examples of Entropy Production and Disposal
The Rate of Entropy Export by the Earth
In the simplest model, the earth is in thermal equilibrium; continuously heated by the sun’s radiation, and cooled by the infrared radiation into the universe.
The solar constant is the power collected at the top of the earth atmosphere by a unit area (1 m2) perpendicular to the light path. This power is remarkably constant, see e.g., (Hickey et al., 1980), and equal to q˙ = 1370 Watts65 per square meter (W/m2). The projection of the sun-lit earth hemisphere in the direction perpendicular to the sun light is πr2e
, where re = 6371 km is the mean volumetric earth radius, or 1/2 of the hemisphere area, and 1/4 of the earth surface area (Ae ≈ 510 × 106 km2).
The Planck temperature of the sun’s radiation is Ts ≈ 5700 K, and the Planck temperature at which the earth radiates its heat is Te ≈ 254 K66. The earth reflects about 30% of the sun radiation, so its surface is reached by only 0.7 of the solar energy. Therefore, the time-averaged flux of entropy exported by the earth into the universe is
where the factor 4/3 comes from the Stefan-Boltzmann law67. This estimate agrees very well with the jE/S = 1.2 W/K-m2 reported by Prof. Arne Stahl (1996).
The Simplest Climate Model
The earth is in thermal equilibrium:
Rate of energy input from the sun = Rate of energy radiation by the earth
Similarly to Frondel, Oertel and R¨ubbelke (2002), I assume that the earth’s atmosphere is a heat-transporting68 gas layer. The surface temperature of the earth is T0 and the Planck temperature of its radiation is Te. The stationary heat flow through the atmosphere occurs at a constant rate:
where Ae is the surface area of the earth. In this simple model, the steady-state rate of energy export from the earth depends on the mean temperature difference between the earth surface and the uppermost atmosphere. The overall heat transfer coefficient, k, depends on how effectively the atmosphere transports heat. With the increasing concentration of heat absorbers (the greenhouse gases) this coefficient decreases, and the earth temperature must go up. At steady state, Second Law of thermodynamics requires the entropy flow rate to satisfy the following equation:
where ˙S0 is the rate of entropy change near the earth surface, and Se is the rate of entropy change at the outer layers of the atmosphere. Therefore, the net rate of entropy generation in the atmosphere due to energy transport is
Since both P and Te are constant, it follows that as the temperature of the earth surface increases, so does the rate of entropy generation in the atmosphere. This positive feedback effect, or domino effect, will intensify the impact of human entropy production on the earth climate. The rate of entropy generation in the atmosphere per unit surface area of the earth defines the specific atmospheric entropy generation rate:
With the numbers used in Eq. (34), this specific rate is equal to 0.11 W/K-m2, not bad for such a simplistic model. For comparison, Stahl (1996) reports 0.2 W/K-m2.
Entropy Generated by a Human
A sedentary human needs about 2400 kcal per day in food to live and work a little. This food consumption translates roughly into an average sustained power of ˙Q = 100 W, i.e., one man = one 100 W bulb shining infrared light for 24 hours a day. This power is dissipated through work, thermal convection, radiation, excrements, etc., and appears as heat at the ambient temperature T0 = 273 + 15 = 288K. Thus the entropy generation rate is
per person. At 3500 kcal per day, a quantity more representative of the U.S. feeding habits, the rate of entropy generation by one person is ˙S = 0.5 W/K, in agreement with (Stahl, 1996). This means, that if one crowds 2-3 people per square meter, they will generate more entropy than the earth can export.
Entropy Generated By Fossil Fuels
In the year 2000, the U.S. burned 83 quads (1 quad = 1 quadrillion or 1015 BTU69) in fossil energy and 2.9 quads in wood, alcohol, etc. For simplicity, I will treat all this energy as the source of heat rejected70 into the earth environment at the mean ambient temperature of T0 = 288 K. The U.S. population was N = 282 million people in 2000. Therefore, in A.D. 2000, the per capita thermal entropy generation rate in the U.S. was
My estimate of the per capita thermal entropy generation rate in the U.S. is somewhat higher than the 35 W/K-person calculated by Stahl (1996).
In the year 2000, the U.S. emitted about 1.65×1012 kg of carbon dioxide by burning fossil fuels (Marland et al., 2004) (1/4 of the global carbon dioxide emissions). The standard molar entropy of carbon dioxide is 213.8 kJ/kmol-K. Therefore, the per capita U.S. rate of generation of chemical entropy of carbon dioxide in the atmosphere:
is much smaller than the corresponding thermal entropy rate in Eq. (41). Unfortunately, this chemical entropy cannot be exported to the universe, and thus accumulates on the earth. The whole world produced 400 quads of energy in the year 2000, therefore the U.S. used roughly 1/4 of it. The per capita entropy rate for the whole world excluding the U.S. was 6 W/K-person, or 1/6 of the U.S. rate. This means that where it really counts, in entropy generation rate, the U.S. society is six times as wasteful as the world at large, including Europe and Japan.
The U.S. thermal entropy generation rate may also be expressed per unit surface area of the country (9,629,100 km2), resulting in the specific anthropogenic entropy rate σ +σa = 0.001 W/Km2, or 0.1% of the net entropy flux exported from the earth. Of course, most of this entropy is generated on a small fraction of the U.S. land area. If all anthropogenic entropy were generated over 0.1% of the U.S. area71, roughly the area of Los Angeles, it would overwhelm the entropy export capacity of the earth. This calculation omits the entropy generation rate to “restore” the environment polluted chemically by the fossil fuel by-products. Nevertheless, the anthropogenic thermal entropy generation is still very small when compared with the capacity of the earth to export entropy. The chemical entropy, in contrast, continuously accumulates on the earth. Even the transport entropy in the atmosphere is generated at a specific rate 100-200 times higher than the mean generation rate of anthropogenic specific entropy in the U.S.. Note that in his interesting paper R¨ubbelke (1998) made a mistake (p. 198) by claiming that the U.S. population produced entropy at the rate of 35 W/K-m2, not 35 W/K-person as calculated by Stahl (1996). The consequences of this mistake influenced erroneously his conclusions about sustainability.
What this calculation does not show, is the fast and irreversible exhaustion of the meager stock of high quality crustal materials (low entropy) that feed our civilization with the accompanying increase of chemical entropy.
B Availability and Irreversibility in Thermal Systems
Because the earth can export entropy by infrared radiation from the outer layers of the atmosphere, in this appendix I define any thermodynamic system on the earth as interacting with the atmosphere only. The atmosphere will be treated as being in stable dynamic equilibrium, and characterized by the constant absolute temperature T0, volume Va, and the hydrostatic pressure, p0 = 1 atm, at sea level. By including within the system as much surface land area, surface water, groundwater, minerals, material, plants, machinery, etc.72, as affected by the process of interest, one is always able to construct the system that interacts with the atmosphere only. For simplicity, chemical entropy generated by the system is not considered here.
Gibbs73 showed that for any process which can occur under these circumstances the quantity defined as
decreases
where E is the total energy of the system, V its volume, S its entropy, and the increment of ,, is taken in the direction of increasing chronological Time.
The process of interest can only occur until the system pressure is uniformly hydrostatic and its uniform temperature is T0. Therefore, the state from which no spontaneous change can occur is the state in which the system has the hydrostatic pressure (p0 at sea level) and the atmospheric temperature T0, and for which Φ has the smallest possible value, Φmin. If only one state of the system results in this minimum value, the system is in stable equilibrium. Otherwise, if there are several states corresponding to the minimum value of Φmin, the system is in neutral equilibrium of maximum stability.
Gibbs74 referred to the difference
where Φ corresponds to the state in question, as the “. . . available energy of the body (our system) and the medium (our surroundings).”
Joseph H. Keenan (1951) later showed that for the system undergoing change from an earlier state 1 to a later state 2, the amount of useful work Wu is
Therefore, for any state 1, the maximum possible useful work done by the system is Φ1 − Φmin. Keenan proposed to call this maximum value availability, Λ. It may be said75 that for any system in the stable atmosphere
and that for the most stable state of the system
From Eq. (46) it also follows that
Keenan also quantified the irreversibility76, I, of a process executed by the system-atmosphere combination:
and showed that
Of course, Keenan’s irreversibility was discovered much earlier and independently by Gouy (1889) and Stodola (1898; 1927)77. Regardless, the irreversibility of a process is equal to the increase of entropy of everything involved in the process multiplied by the temperature of the atmosphere. One may use Eq. (51) in the differential form, and per unit area of the earth surface, by writing
where σI is the specific rate of irreversibility, σa is the specific rate of entropy increase in the atmosphere generated by the process, and σ is the specific rate of entropy increase of the system. Note that as the atmospheric temperature increases, so does the irreversibility of any process on the earth.
From Appendix A it follows that we can treat the atmosphere as an open system that exports entropy to the universe with the flux jE/S calculated from Eq. (34). The energy transport through the atmosphere generates entropy at the specific rate of σt calculated from Eq. (39). Thus, we may rewrite Eq. (52) as
Using equation (53), we can define sustainability as
For sustainability, equation (54) requires that the net rate of increase of entropy of everything at every place on the earth and for all times be less or equal to zero! Note that the process and energy transport increase the entropy of the earth and the atmosphere, and low-temperature heat radiation decreases it.
Remark 15 As derived, Eq. (54) is quite deceiving. The anthropogenic part of the thermal entropy generation rates, σ + σa, can only be sustainable if this entropy is generated in cycles in which all process materials are completely recycled, and all chemical entropy is transformed into thermal entropy. If we rely on a finite stock of fossil energy, then even if the entropy generation rate in a process is much lower than the entropy export flux, the process is never sustainable. Therefore, sustainability can only be discussed in the context of cyclic processes.
Over an arbitrary time interval [τ1, τ2], we can write the global condition of sustainability of all cyclic processes on the earth as
where SE(τ1, τ2) = jE/S Ae(τ2, τ1) is the total thermal entropy exported by the earth over the time interval [τ1, τ2], and St(τ1, τ2) = σtAe (τ2, τ1) is the corresponding thermal entropy generated in the atmosphere by the steady-state energy transport to the universe.
C Is Economic Sustainability Possible?
I have already demonstrated that anything sustainable on the earth must involve a closed material loop (a cycle) which is driven by the sun. Solar energy is like a fine mist: it dribbles at a constant rate on every square inch of the earth’s surface. We cannot increase its flow rate, it dries up overnight, and we cannot store it easily. So one may ask legitimately: is solar power enough to drive the world economy, and if so what constraints does it impose?
The time- and area-average solar energy flux in the U.S. is &asmp;200 W/m2 at the earth surface. At more moderate latitudes this flux goes down to about 100-150 W/m2, and in the tropics it can be as high as 300 W/m2. Thirty percent of the earth’s surface, 153×106 km2, is land. Suppose that 1% of land mass on the earth were covered with solar cells that were 10% efficient, and received only 100 W/m2 of solar energy. The total solar power converted by these cells to electricity would then be 1.5 × 104 gigawatts (1GW = 109W). Currently, the mean world power consumption is about 1.3 × 104 GW. Therefore covering one percent of the earth’s land with solar cells would deliver power equal to the mean world power consumption. For the U.S., it would take closer to 3% of the land area, or 300,000 km2 (the area of Poland) to replace the entire mean fossil and nuclear power. There are problems, however, with these calculations:
2. Mass production of solar cells will generate associated chemical waste (high chemical entropy, which cannot be exported by the earth).
3. There are few big transmission lines in the hot barren areas of the world.
4. The peak power consumption in the world can be several times the mean power, and power is needed at night.
5. A significant portion of the world power (over 1/3 in the U.S.) is used by automobiles.
6. Large-scale manufacturing of solar cells does not exist (Hayden, 2002).
7. At 1 U.S. dollar per watt (1/7-1/5 of the current U.S. price, given sufficient manufacturing capacity), it would take 15 trillion dollars to replace most of the fossil and nuclear energy worldwide with solar cells. This amount would probably double if massive new transmission grids and the required transformers were to be built worldwide.
The first and the last item above suggest that decentralization of power generation is necessary. With small and micro power plants, one avoids access roads, big transformers, and long transmission lines. Covering large areas with solar cells is also impossible in the mountains and forests. The second item requires an intensive research and development effort to weigh the solar cell efficiency and reliability versus the production costs, the use of exotic rare-earth elements, and the generation of chemical waste.
The fourth item dictates a dramatic adjustment of industrial activity: (1) Most factories would have to shut down before sunset. (2) For winter and nocturnal use, energy could be stored as hydrogen from solar-driven water electrolysis. (3) The industrial world would have to slow down, and reassess its social priorities, in sharp contrast to my introductory remarks in Part II.
Solar Cells vs. Biofuels. The superiority of solar cells over any biofuel can be illustrated as follows. The cumulative energy balance in Part I shows that the unsustainable industrial corn farming captures about 100 GJ/ha per crop that lasts, say, 120 days.
Because soybean or another legume is planted afterwards, the annualized energy yield from corn remains the same. The product, corn grain, is a fossil fuel which is later converted into another fossil fuel, ethanol, at a large expense of fossil energy. The ethanol yield is about 74 GJ/ha-yr, and the energy conversion efficiency of a fuel cell is 60%. Thus, corn can deliver 74×0.60 = 44 GJ/ha-yr as electricity. The fossil fuel inputs exceed the calorific value of the ethanol by about 2-20 GJ/ha-yr. In Part III, I showed that a fuel cell can deliver about 46 GJ/ha-yr as electricity from the industrial corn-ethanol cycle, but the restoration work is at least twice as large. During one year, an inefficient solar cell that converts only 10% of only 100 W/m2 will sustainably produce 3000 GJ/ha of electricity, see Figure 48. Therefore, the solar cells described above can produce 100 times more electricity than the corn ethanol(hydrogen)-burning fuel cells. One hectare of solar cells placed anywhere can therefore free 100 hectares of fertile agricultural land from industrial corn, and allow for the low-intensity, diversified, and almost sustainable agriculture. The socially and scientifically defensible choice is clear78.
D Efficiency of a Fuel Cell System
In their Science paper, Deluga et al. (2004) claim the following:
. . . Further, combustion used for transportation has 20% efficiency as compared with up to 60% efficiency for a fuel cell. . .The efficiency of these processes for a fuel cell suggests that it may be possible to capture >50% of the energy from photosynthesis as electricity in an economical chemical process that can be operated at large or small scales. (p. 996).
Following Deluga et al.’s paper and common chemical engineering knowledge, I will assume the following:
2. The catalytic reaction has 100% selectivity and >95% conversion efficiency. I will assume here the conversion efficiency η1 = 0.96.
3. The ethanol-water reactant mixture for the catalytic conversion to hydrogen is ultra pure (on the order of 99.9999% pure C2H5OH and H2O). Otherwise, any and all of the impurities listed in Footnotes 81 and 82, and carbon deposition, will destroy the catalyst and reactor. Therefore, one must separate all impurities from the 8 − 10% alcohol81-yeast-rest beer82 by multiple distillations, rectification, and molecular sieve exclusion (Maiorella, 1985). As described in Part II, all these processes consume irreversibly large amounts of free energy.
4. The reaction products are hydrogen, carbon dioxide, carbon monoxide, water vapor, plus whatever other impurities. The hydrogen fuel separation from all other components of reactor effluent is almost perfect. Compared with the reference hydrogen of 99.9999999% purity, even tiny amounts of impurities can cause a noticeable drop in performance of a fuel cell83. Some of these impurities are CO (at 5-10 ppm), SO2 (at 2 ppm), H2S (at 1-2 ppm), HCHO (at 10-20 ppm), and HCOOH (at 50-100 ppm).
5. In summary, by the time we are ready to use the ethanol-derived hydrogen in a fuel-cell/electric car, we have spent a lot of free energy on picking ethanol, water, and hydrogen molecules; much more than on distilling the relatively dirty ethanol to be mixed with gasoline. The latter free energy expenditure is ≈15 MJ/L EtOH, or >50% of the ethanol’s high heating value.
After Bossel (2003a), I will summarize efficiency of a Proton Exchange Membrane (PEM) fuelcell as follows. In fuel cells, gaseous hydrogen is combined with oxygen to water. This process is the reversal of the electrolysis of liquid water and should provide an open circuit voltage of 1.23V (Volts) per cell. Because of polarization losses at the electrode interfaces the maximum voltage observed for PEM fuel cells is between 0.95 and 1.0 V. Under operating conditions the voltage is further reduced by ohmic resistance within the cell. A common fuel cell design voltage is 0.7 V.The mean cell voltage of 0.75 V may be representative for standard driving cycles. Consequently,the average energy released by reaction of a single hydrogen molecule is equivalent to the product of the charge current of two electrons and the actual voltage of only 0.75 V instead of the 1.48 V corresponding to the hydrogen high heating value84. Therefore, in automotive applications, PEM fuel cells may reach mean voltage efficiencies of
However, there are more losses to be considered. The fuel cell systems consume part of the generated electricity. Typically, automotive PEM fuel cells consume 10% or more of the rated stack power output to provide power to pumps, blowers, heaters, controllers, etc. At low power demand the fuel cell efficiency is improved, while the relative parasitic losses increase. The small-load advantages are lost by increasing parasitic losses. Let us assume optimistically that for all driving conditions the net power output of an automotive PEM fuel cell system is about η3 = 0.9 of the power output of the fuel cell stack.
Depending on the chosen drive train technology, the DC power is converted to frequency modulated AC or to voltage-adjusted DC, before motors can provide motion for the wheels. Energy is always lost in the electric system between fuel cell and wheels. The overall electrical efficiency of the electric drive train can hardly be better than η4 = 0.9.
By multiplying the efficiency estimates, one obtains for the maximum possible tank-to-wheel efficiency of a hydrogen fuel cell vehicle
or 38%. This optimistic estimate agrees with another analysis (31-39%) (Fleischer and Ørtel, 2003), and is significantly less than the 60% used by the reckless promoters of a hydrogen economy and hydrogen fuel cell vehicles.
E Cumulative Exergy Consumption in Steel Production
The primary commercial iron ores in the world are hematite (Fe2O3) and magnetite (Fe3O4). Taconite, the principal iron ore mined in the United States, has a low (20 – 30%) iron content and is found in hard, fine-grained, banded iron formations. About 99% of iron ore is used in the iron and steel industry. Scrap can be considered a supplement to iron ore in the steelmaking process but is limited as a major feed material owing to inadequate supply of high-quality scrap. Alternatives, such as direct reduced iron (DRI), are also available, and their use continues to grow.
Ore is put into a blast furnace and smelted to produce molten iron, which is then converted to steel by removing most of the remaining carbon in a basic oxygen furnace (BOF). Almost all molten iron goes directly to the BOF, eliminating the molds. The blast furnace product is usually referred to as pig iron.
Iron ore consumption in the U.S. in 2003 was 61 million metric tonnes (Mt), a rise of slightly more than 1 Mt from that of 2002. There was an average of 30 blast furnaces active during 2003, up slightly from that of 2002 when the average number of blast furnaces operating was 29, the lowest since 1961. Accordingly, pig iron production at 40.6 Mt in 2003 was slightly above that of 2002, which had been the lowest since 1982. Crude steel production at 94 Mt increased by 2% compared with that of 2002. Steel demand remained constant at revised 2002 levels of 107 Mt. The large difference between ore production and steel demand is explained by examining the minimill sector and net imports of iron ore substitutes. In 2003, the minimill sector of the steel industry produced more than 50% of the crude steel in the United States. Minimills do not use iron ore as feedstock; instead they use iron and steel scrap, and some DRI in electric arc furnaces (EAF). For a more detailed summary, see Jorgenson & Kirk (2003).
Several literature estimates of primary energy consumption in producing steel via integrated U.S. mills and BOF are listed in Table 26. The same-source estimates of primary energy consumption in producing steel from 100% scrap in EAF are listed in Table 27. The embedded energy and equivalent CO2 emissions in SAE 1045 and SAE 15V45 steel are listed in Table 28.
E.1 Steel component manufacturing
As an example, the track roller shaft in a Caterpillar tractor has been investigated in (Beloff et al., 2004). This track roller is conventionally produced with medium carbon steel, typically SAE 1045 or modified SAE 5038. Due to physical and cost benefits at least within the “shape and treat” manufacturing stage of the lifecycle, the part is now produced with microalloyed steel, namely SAE 15V45.
In addition to the primary energy contained in the energy sources, exergy includes work that is available in other materials that contribute to the lifecycle. For simplicity, only iron and minerals that make up the compositions of the steels have been included in (Beloff et al., 2004) in addition to the primary energy, i.e., wastes and auxiliary materials have been ignored. With these assumptions,the primary energy embedded in the track roller is 30 and 27 MJ/kg-part, respectively, for SAE 1045 and SAE 15V45 steels. The standard chemical exergy embedded in these two steels is 6.7 MJ/kg. The incomplete cumulative exergy consumption (CExC) is 37 and 34 MJ/kg-part respectively. The GHG emissions are about 2.7 kg CO2 equiv./kg-part. Other, apparently more complete estimates of cumulative exergy consumption in steelmaking (Szargut et al., 1988) are listed in Table 29. They range from 46 to 84 MJ/kg of finished steel products.
Remark 16 The average cumulative exergy consumption per kg of steel in machinery is between 34 and 84 MJ/kg. Taking into account the extensive infrastructure this machinery uses to function, and the concomitant environment pollution, the steel-only estimate should at least double (Wall, 1997) to 68-168 MJ/kg.
Notes
1For a definition, see Footnote 33.
2Intergovernmental Panel on Climate Change.
3The endlessly repeated harvest of whole plants that grow on the same soil would have to be sustainable.
4The energy of dry corn grain minus the fossil energy inputs per hectare and per crop.
5The reported net energy yields of perennial grasses, sugarcane, etc., seem somewhat high to me.
6“Ethanol production makes huge amounts of the nation’s corn disappear – some 1.4 billion bushels went into ethanol production in 2004 – and that affects overall corn supply and helps shore up corn prices nationwide.” National Corn Growers Association, https://www.ncga.com/ethanol/main/economics.htm, accessed July 2, 2005.
7Source: USDA NASS database: www.usda.gov/nass/
8Source: 2004 world production of corn: www.cbot.com/cbot/pub/static/files/c−wprod.gif.
9Source: Farm Subsidy Database, https://www.ewg.org/farm, accessed July 2, 2005
10The notation kg/ha-crop stresses that the time unit in the average fluxes is the duration of a single crop, e.g., 120 days in the case of corn plants.
11The lowest average yield of corn in the U.S., 18.2 bushels/acre, was recorded in 1901 and 1934, USDA, https://-usda.mannlib.cornell.edu/data-sets/crops/96120/trackrec2003.txt
12Between 1960 and 2000, the use of nitrogen fertilizer increased 5-fold (USDA-NASS database).
13(Lide, 1994), p. 15-46.
14I would like to thank Dr. Drew Ronneberg of Technology and Management Services, Inc. for pointing out my error in not accounting for the gain of one water molecule per glucose unit in starch hydrolysis, and referring me to the report by Dr. Michael S. Graboski (Graboski, 2002).
15Two tenth of one percent is 20 parts in 10000 parts of mean insolation. Roughly half of these 20 parts becomes corn grain.
16Good field practices might include: (1) Soybean/corn crop rotation to naturally bind nitrogen and limit synthetic fertilizer use; (2) Corn stover decomposition in the field to conserve soil nutrients and limit erosion; and (3) Moderate soil tilling, or no tilling, to diminish loss of soil carbon and erosion.
17In Part II, I will show that the use of synthetic fertilizers makes farming unsustainable.
18This 8.5% overall loss lumps the losses in broken corn kernels and foreign matter (nominally 3% by mass for No. 2 yellow corn), in starch separation and hydrolysis, fermentation, distillation/rectification, and ethanol trans- portation and distribution. The fermentation process has several byproducts: n-propyl, isobutyl, amyl, iso-amyl, 1,2,3-propanetriol (glycerol) and higher alcohols; acetic aldehyde and acid; etc., see (White and Johnson, 2003), page 710; also see Appendix D for more details. The fermentation selectivity to ethanol can be less than 90%.
19For comparison, a recent feasibility study for a new ethanol plant (International, 2001) projects 13.08 MJ/L EtOH in methane, and 1.675 MJ/L EtOH in electricity, for the total of 14.8 MJ/L EtOH, excluding transport and commute costs. This study seems to contain some mistakes. For example, the efficiency of grain conversion into ethanol is overestimated, and the amount of feed water is significantly underestimated.
20The energy of dry corn grain minus the fossil energy inputs per hectare and per crop.
21“A group of farmers, environmentalists, automakers, grain processors, and government researchers.”
22Therefore, any fuel or technology can be declared as “sustainable,” whenever there exists a group of people who feel good about it, and say that it is!
23My favorite: Permaculture: Principles and Pathways Beyond Sustainability by David Holmgren, published by Holmgren Design Services (July 2003).
24Georgescu-Roegen (1971), page 304.
25Preaching alone will not do. People will never choose less fulfilling life styles without coercion. This is why communism, or any other totalitarian “ism,” can never work; they strive to convert the thinking individuals into slaves or working animals. Says Percy Williams Bridgman, (1955), p.114, italics mine: “The individual is the unit in terms of which all our social concepts ultimately find their meanings.”
26The word analytic means well-defined mathematically in space and/or time.
27The process is not defined outside its time interval.
28Started in 1824 with a memoir, R´eflexions sur la puissance motrice du feu et sur les machines propres `a d´evelopper cette puissance, on the efficiency of steam engine by a French engineer, Sadi Carnot (1943).
29Initially free heat was defined as the heat which can be exchanged between a hotter body and a colder one, and which can move a turbine in power station. If the hotter body, i.e., a steam boiler, remains unchanged, and the colder body, i.e., the environment, warms up, the amount of free heat goes down and the power station produces less electricity, as happened in Europe during the record-breaking summer heat wave of 2003.
30Bridgman disagrees, (1955), p. 265.
31Time is a notion of extraordinary complexity. Here I use the historical or chronological Time, as opposed to the mechanical clock time.
32Not only biological life, but also social life. Consider the following comment made by Joseph Samaha in the daily Al Safir of Beirut about the desperately dissipative, high-entropy political situation in the Middle East: “Let us expel every mediator. Let us banish every international organization. Let the situation collapse. Let electricity and water be cut off. Let the pumping of oil stop. Let theft prevail. Let the universities and schools close down. Let businesses go bankrupt. Let civilian life break down.” Source NYT, August 21, 2003, page A13.
33eco – From late Latin oeco- household, from Greek oik-, oiko-, from oikos house habitat or environment (Webster, 1993). Ecosystems are the earth’s households, and ecology is the study of these households.
34A social science concerned chiefly with description and analysis of the production, distribution, and consumption of goods and services; from Greek oikonomica – skilled in the management of a household(Webster, 1993).
35(Jevons, 1866), Preface, pp. vi-vii, my italics. Jevons could not possibly imagine that coal, or any other fossil fuel, could be wanting at the rate we need to produce it in the 21st century, regardless of the price.
36In fact, it is more difficult to extract crude oil than coal. After we finish exploiting an oilfield, 1/2 to 2/3 of theoil present initially in the rock interstices is left there forever. Also, producing conventional crude oil and natural gas at the incredibly high rates required by the world economy will soon be physically impossible, regardless of their prices. Therefore substitution of crude oil by natural gas will be impossible. As pointed out by Dr. Ronneberg, economists simply do not comprehend this looming calamity.
37With the notable exception of Georgescu-Roegen (1971).
38Natural soil fertilizers, soil-bonding humus, interstitial water, etc.
39Unless the soil is a part of an ecosystem that recycles all mass, see Section 10.
40In the 1930’s, the young physicists became so confused by statistical thermodynamics that a famous thermody-dynamicist, Percy Williams Bridgman (1955), wrote an essay on the impossibility of constructing a machine that “shall violate the second law of thermodynamics on a scale large enough to be commercially profitable (pp. 236-268).”
41J. Clerk Maxwell (2001) imagined a tiny demon posted near a microscopic swinging door separating two gases
A, and B of equal temperature. The demon is instructed to open and close the door “so as to pass only the swifter molecules from A to B, and only the slower molecules form B to A.” Clearly this demon can make the gas in B hotter and in A cooler. Therefore, Maxwell’s demon creates low entropy – or does he?
42According to Stefan G¨oßling, entropy generation per ton of copper produced from ore is 52 MJ/K, and only 12 MJ/K for copper produced from scrap; for reference, see the caption of Figure 23.
43Georgescu-Rogen, (Georgescu-Roegen, 1971), Chapters IX and X.
44When watching an SUV commercial, I often see a monstrous truck carelessly damaging a low-entropy fragile ecosystem, a pristine meadow, river bed, or an alpine mountain slope. Thus the SUV commercials are a good metaphor for the interactions of the present-day economics with the environment.
45(C´ep`ede et al., 1964), p. 309.
46A process that cycles living organisms. Only the solar energy and waste heat flow across the ecosystem boundary, everything else is recycled, cf. Section 10.
47This fraction may be very small. For example, the vast majority of carbon on the earth is bound in the carbonate rocks. No one in their right mind would dream of extracting this carbon. See also footnote 36.
48Therefore hiding our waste by injecting it into the oceans, aquifers, or burying it in shallow graves – landfills – will always come back to haunt us.
49NYT, August 20, 2003: “Crews have completed the removal of more than 12 metric tons of weapons-grade plutonium from the Rocky Flats (CO) nuclear weapons site as part of a $7 billion cleanup effort that is expected to be finished in 2006, 12 years ahead of schedule. The plant manufactured plutonium triggers for 40 years until it was closed in 1989 for safety violations. The plutonium has been shipped to South Carolina; lower-grade nuclear waste will be sent to New Mexico. The 6,000-acre Rocky Flats site is expected to become a wildlife refuge.” In other words, the cost of picking and sorting the plutonium waste is $583/g, compared with $11/g to buy gold.
50Pimentel (2004c) observes: “Between 1900 and 1938, the early [U.S.] farmers were probably mining the soil of nutrients and soil erosion was quite severe. At that time, most farmers kept livestock and were applying manure to the land. Most did not apply the manure until spring, when more than half of the nitrogen had escaped into the atmosphere. Most of the corn was grown in rotation. If the corn were grown after a legume crop, some nitrogen would be available to the corn crop. Although manure was being applied, it probably was applied in the neighborhood of only 5 tonnes of stored manure per hectare, and thus would have only about 12 to 15 kg/ha of nitrogen. For a corn yield of 1600 kg/ha the manure application only would provide a minimum amount of nitrogen.”
51Not necessarily the same field.
52About 11 giga liters.
53The U.S. Energy Information Agency (EIA) (2002), Appendix A, page A3, my italics.
54One may dispute this last number to the extent that ammonium nitrate is not used as fertilizer.
55The rule of thumb is that corn needs 1000 – 1800 kilograms of water per kilogram of grain produced. This rule translates into 86-150 cm of water requirement, see, e.g., https://www.jica.go.jp/english/publication/network/-net−vol18/02.html.
56A Google search yields BOD values between 600 and 9200 mg/L in the wastewater streams from wet- and dry milling ethanol refineries that use different biomass feeds.
57For an in-depth analysis of the deadly industrial agriculture, see Kimbrell et al. (2002).
58See Remark 6. Without synthetic fertilizers, I would have to use 1500 kg/ha-crop of corn as the average yield.
59As shown by (Bossel, 2003a) and in Appendix D, a 60%-efficient PEM fuel cell-powered car cannot exist! The real-life efficiency of such a car is about 38%. The reckless promoters of a hydrogen economy neglect to mention this important downward correction.
60Corn subsidies, OXFAM.
61Excise Taxes, Reuters, Washington, Nov. 15, 2003.
62Cat Lazaroff – ENS, 3 Oct., 2002.
63According to the Center for Responsive Politics, https://www.opensecrets.org/industries/indus.asp?Ind=A, between 1990 and 2005, Agribusiness paid $355 534 846 to elected officials, 31% to Democrats and 69% to Republicans. The peak donations occurred in the 2000 and 2002 election cycles, exceeding 59 and 54 million dollars, respectively. The 2004 election cycle donations exceeded 53 million dollars.
64Cat Lazaroff – ENS, 3 Oct 2002.
651 Watt = 1 Joule/second.
66The actual temperature of the earth surface is about 34 K higher due to the greenhouse effect. Therefore there is entropy generation in the atmosphere, see the section below.
67See Szargut’s monograph, (1988), page 72, Eq. (2.53).
68Heat transport through the atmosphere proceeds through turbulent convection and mixing, water evaporation and condensation, thermal conduction, and radiation.
691 BTU = 1055 Joules of energy.
70In reality, a portion of the fossil energy, probably 20-30%, generates work, resulting in less heat dumped into the environment. Therefore, this analysis provides the uppermost bound on the entropy generation rate.
71A physical impossibility!
72The entire globe, if necessary.
73(Gibbs, 1994), p. 40.
74(Gibbs, 1994), p. 53; my comments in italics.
75(Keenan, 1951), Eqs. (12) and (13).
76(Keenan, 1951), Eqs. (31) – (36).
77In particular, Volume II of Stodola’s monograph (1927), pp. 1271-1330, brings a thorough discussion of The Highest Possible Conversion into Work on the Basis of the Second Law of Thermodynamics.
78Some, e.g., (Sheehan et al., 2004), argue that corn should be farmed continuously (with no crop rotation): the whole plants are harvested, the grain is processed for ethanol, and the rest is burned for energy. This energy supply scheme requires 2-10 times more field chemicals (see Part I), irreversibly depletes and damages the soil, and is even more unsustainable than a single corn crop (see Parts II and III).
79Rhodium is a precious metal whose price is about US$30 000/kg, 3×more expensive than gold, https://www.kitco.com/charts/rhodium.html.
80The nanoparticles of cerium dioxide are called ceria, and cost $250/kg, https://www.advancedmaterials.us/58N-0801.htm
81Alcohol dissolves a large number of substances insoluble in water and acids, such as many inorganic salts, phosphorus, sulphur, iodine, resins, essential oils, fats, coloring matters, etc. (Wright, 1994).
82The beer obtained by mashing and fermenting consists of volatile components, such as water, alcohols (mostly ethyl, but also traces of methyl, propyl, butyl, amyl, and other alcohols – depending on the impurities in glucose), essential oils, and a little acetic acid; and of non-volatile substances, such as cellulose, dextrine (an intermediate product of starch hydrolysis), unaltered sugar and starch, mineral matter, lactic acid, glycerol, etc.
83Japan Automotive Research Institute (JARI), DOE Hydrogen Codes and Standards, Coordinating Committee Fuel Purity Specifications Workshop, April 26, 2004, https://eere.energy.gov/hydrogenandfuelcells/pdfs/-fuel−purity−notes.pdf
84According to Faraday’s Law, the standard enthalpy of combustion of hydrogen, ΔH0f = −285.9 kJ/mol, can also be expressed as an electrochemical potential (“standard potential”) U0 = −Δ>H0f/neF> = 1.48 V with ne = 2 being the number of electrons participating in the conversion and F = 96485 Coulomb/mol the Faraday constant.
References
Allison, F. E. 1973, Soil Organic Matter and Its Role in Crop Production, Elsevier, New York.
ARB 2005, A summary of the staff’s assessment regarding the effect of ethanol in California gasoline on emissions, Draft report, Air Resources Board Sacramento, CA 95812,www.arb.ca.gov/fuels/gasoline/meeting/2005/030105etohrpt.pdf.
Avers, C. J. 1976, Cell Biology, D. van Nostrand Company, New York.
Barber, S. A. 1977, Our Land and Its Care, Chapt. Plant nutrient needs, pp 41 – 51, The Fertilizer Institute, Washington, D.C.
Beloff, B., Tanzil, D., and Chuzhoy, L. 2004, Assessment of Potential Life Cycle Environmental Impacts of Microstructure-Level Simulation for a Steel Component: An Exploratory Research, Final project report, grant number dmi-0245431, National Science Foundation, Washington, DC, www.bridgestos.org/NSFFinalReport.pdf.
Bender, K. and Hill, L. (eds.) 1997, Adjusting for Moisture – Equivalent Bushel Workshop, Vol. AE4720, Urbana-Champaign, University of Illinois, Department of Agricultural and Consumer Economics.
Benham, B. L. 1998, Irrigating Corn, University of Nebraska, South Central Research and Extension Center, Clay Center, G98-1354-A, https://ianrpubs.unl.edu/fieldcrops/g1354.htm.
Berndes, G., Hoogwijk, M., and Van den Broek, R. 2003, The contribution of biomass in the future global energy supply: A review of 17 studies, Biomass & Bioenergy 25: 1–28.
Berthiaume, R., Bouchard, C., and Rosen, M. A. 2001, Exergetic evaluation of the renewability of a biofuel, Exergy Int. J. 1(4): 256–68.
Biermann, S., Rathke, G. W., H¨ulsbergen, K. J., and Diepenbrock, W. 1999, Energy Recovery by Crops in Dependence on the Input of Mineral Fertilizer, Report, Martin-Luther-University Halle-Wittenberg, Agroecological Institute and Institute of Agronomy and Crop Science, Halle (Saale).
Blais, J.-F., Mamouny, K., Nlombi, K., Sasseville, J.-L., and L´etourneau, M. 1995, Les mesures deficacit ´e ´energ´etique ´electrique dans le secteur de leau, Scientific Report 405, INRS-Eau, Qu´ebec, Sasseville, J.-L. and Blais, J-F., eds., Les mesures deficacit´e ´energ´etique pour l´epuration des eaux us´ees municipales, Vol. 3.
Bossel, U. 2003a, Efficiency of Hydrogen Fuel Cell, Diesel-SOFC-Hybrid and Battery Electric Vehicles, Technical report, European Fuel Cell Forum, Morgenacherstrasse 2F, CH-5452 Oberrohrdorf, Switzerland, https://www.efcf.com.
Bossel, U. 2003b, Well-to-Wheel Studies, Heating Values, and the Energy Conservation Principle, Technical report, European Fuel Cell Forum, Morgenacherstrasse 2F, CH-5452 Oberrohrdorf, Switzerland, https://www.efcf.com.
Bossel, U., Eliasson, B., and Taylor, G. 2003, The Future of the Hydrogen Economy: Bright or Bleak – Final Report, April 15, Technical report, https://www.efcf.com/reports/hydrogen−economy.pdf.
Bridgman, P. W. 1955, Reflections of a Physicist, Philosophical Library, Inc., New York. BUWAL 1990, Adapted by PricewaterhouseCoopers Ecobilan, Paris, in DEAM lifecycle assessment database, Environmental series no. 132, Swiss Federal Office of Environment, Forests and Landscape, Geneva, Switzerland.
Carnot, S. 1943, Reflections on the Motive Power of Heat and on the Machines Fitted to Develop This Power, The American Society of Mechanical Engineers, New York.
Castorph, D., Kollera, M., and Waas, P. 1999, Brennwert und Heizwert (The High and Low Heating Values), Technical report, Fachhochschule M¨unchen, FB 03, Dachauer Straße 98 b, 80335 M¨unchen, https://www.fm.fh-muenchen.de/labore/waas/skripten/kap11.pdf.
Celia, M. A. 2002, How hydrogeology can save the world – An Editorial, Ground Water 40(2): 113.
C´ep`ede, M., Houtart, F., and Grond, L. 1964, Population and Food, Sheed and Ward, New York.
Davis, M., Balog, F., Nemanich, G., Katsaros, A., J., O., and Niedzwiecki, A. 2002, National Hydrogen Energy Roadmap – Toward a More Secure and Cleaner Energy Future for America – Production – Delivery – Storage – Conversion – Applications – Public education and outreach, Technical report, Based on the results of the National Hydrogen Energy Roadmap Workshop Washington, DC, April 2-3, 2002, U.S. DOE, https://www.eere.energy.gov/hydrogenandfuelcells/pdfs/national−h2−roadmap.pdf.
Deluga, G. A., Salge, J. R., Schmidt, L. D., and Verykios, X. E. 2004, Renewable hydrogen from ethanol by authothermal reforming, Science 303: 993–996.
DOE 2003, Hydrogen Fuel Cells & Infrastructure Technologies Program, https://www.eere.energy.gov/hydrogenandfuelcells/mypp/ click on Appendices.
Domalski, E. S., Jobe Jr., T. L., and Milne, T. A. (eds.) 1987, Thermodynamic Data for Biomass Materials and Waste Components, The American Society of Mechanical Engineers, United Engineering Center, 345 East 47th Street, New York, N.Y. 10017.
Dresselhaus, M., Crabtree, G., and Buchanan, M. 2003, Basic Research Needs for the Hydrogen Economy, Technical report, Argonne National Laboratory, Basic Energy Sciences, U.S. DOE, https://www.sc.doe.gov/bes/hydrogen.pdf.
EIA 2002, Emissions of Greenhouse Gases in the United States, 2001, U.S. Department of Energy, Energy Information Administration: https://www.eia.doe.gov/oiaf/1605/gg02rpt/pdf/appendixa.pdf, etc.
Elliott, S. S., Keim, N. L., Stern, J. S., Teff, K., and Havel, P. J. 2002, Fructose, weight gain, and the insulin resistance syndrome, Am. J. Clin. Nutr. 76: 911–22.
Fleischer, T. and Ørtel, D. 2003, Impact and consequences of fuel cells technology on sustainable development, Technical report, Institut f¨ur Technikfolgenabsch¨atzung und Systemanalyse (ITAS), Prospective Technology Studies Joint Research Centre.
Frink, C. R., Waggoner, P. E., and Ausubel, J. H. 1999, Nitrogen fertilizer: Retrospect and prospect, Proc. Natl. Acad. Sci. 96: 1175–1180.
Frondel, M., Oertel, K., and R¨ubbelke, D. 2002, The domino effect of climate change, International Journal of Environment and Pollution 17(3): 201–210.
Fruehan, R. J., Paxton, H. W., and Giarratani, L. 1994, A Vision of the Future Steel Industry,Report prepared for the u.s. doe, sponsored by the sloan steel industry competitiveness study,Carnegie Mellon University.
Georgescu-Roegen, N. 1971, The Entropy Law and the Economic Process, Harvard University Press, Cambridge, Massachusetts.
Gibbs, J. W. 1994, The Scientific Papers of J. Willard Gibbs, Ph. D. , LL. D. , Vol. I, Thermodynamics, Ox Bow Press, Woodbridge, Connecticut.
Gill, A. B. 1984, Power plant performance, Butterworths, London.
Gouy, G. 1889, About available energy (in French), Journal Physique II 8: 501–518.
Graboski, M. S. 2002, Fossil Energy Use in the Manufacture of Corn Ethanol, Report prepared for the National Corn Growers Association, Colorado School of Mines.
Haasen, P. and Cahn, R. W. (eds.) 1996, Physical Metallurgy, North Holland, Amsterdam, 4th edition.
Hamelinck, C. N. 2004, Ph.D. thesis, Utrecht University, Faculteit Scheikunde.
Hancock, B. 2005, EMFAC Modeling Change Technical Memo: Correction factor for increased evaporative emissions due to ethanol replacement in oxygenated gasoline, www.arb.ca.gov/fuels/gasoline/meeting/2005/030105etohapp.pdf, California Air Resources Board, Sacramento, CA 95812.
Hayden, H. C. 2002, The Solar Fraud: Why Solar Energy Won’t Run the World, Vales Lake Publishing Llc., New York.
Heichel, G. 2004, Private Communication, University of Illinois.
Hickey, J. R., Stowe, L. L., Jacobowitz, H., Pellegrino, P., Maschhoff, R. H., House, F., and Vonder Haar, T. H. 1980, Initial solar irradiance determination from Nimbus-7 cavity radiometer measurements, Science 208: 281–283.
Hodge, C. 2002, Ethanol use in US gasoline should be banned, not expanded, Oil&Gas Journal Sept. 9.
Horne, A. J. 1991, Selenium detoxification in wetlands by permanent flooding, I. Effects on a macroalga, an epiphytic herbivore, and an invertebrate predator in the long-term mesocosm experiment at Kesterson Reservoir, Water, Air, and Soil Pollut. 57: 43.
Horne, A. J. 1994, Environment, Marcel Dekker, New York.
Horne, A. J. and Gregg, J. H. 1993, Short-term distribution and fate of trace metals in a constructed wetland receiving treated municipal wastewater: A microcosm study using radiotracers, Report 93-4, University of California, Berkeley, Environmental Engineering and Health Sciences Laboratory.
Horne, A. J., Roth, J. C., Barrett, N., Commins, M. L., and Johnson, P. 1994, Progress report for the diagnostic study of Walker Lake, Nevada (July 1992-October 1993), Report, University of California, Berkeley, Environmental Engineering and Health Sciences Laboratory.
IDEMAT 2001, Material selection software, www.io.tudelft.nl/research/dfs/idemat/index.htm,Faculty of Design, Engineering and Production, Delft University of Technology, The Netherlands.
IEA 2000, International Energy Agency: Energy Statistics of OECD Countries, 1999-2000.
International, B. 2001, East Kansas Agri-Energy Ethanol Plant Feasibility Study, BBI International, PO Box 159, Cotopaxi, Colorado 81223, (719) 942-4353, https://www.ekaellc.com/about/EKAE−FS−May−2001.pdf.
IPCC 1997, Greenhouse Gas Inventory Reference Manual: Revised 1996 IPCC Guidelines for National Greenhouse Gas Inventories, Report Vol. 3, p. 1.53, Intergovernmental Panel on Climate Change, Paris, France, www.ipcc.ch/pub/guide.htm.
Jasinski, S. M. 2002, Phosphate rock, https://minerals.usgs.gov/minerals/pubs/commodity/phosphate−rock/phosmyb02.pdf.
Jevons, S. W. 1866, The Coal Question: An Inquiry Concerning the Progress of the Nation and the Probable Exhaustion of Our Coal Mines, Macmillan & Co., London, 2nd edition.
Jorgenson, J. D. and Kirk, W. S. 2003, Iron Ores, https://minerals.usgs.gov/minerals/pubs/commodity/iron−ore/feoremyb03.pdf, Also see USGS, https://minerals.usgs.gov/minerals/pubs/commodity/iron−ore/.
Kartha, S. and Larson, E. D. 2000, Bioenergy primer: Modernised biomass energy for sustainable development, Technical Report UN Sales Number E.00.III.B.6, United Nations Development Programme, 1 United Nations Plaza, New York, NY 10017, USA.
Keenan, J. H. 1951, Availability and irreversibility in thermodynamics, The British Journal of Applied Physics 2: 183–192.
Keith, D. W. and Farrell, A. 2003, Rethinking hydrogen cars, Science 301: 315–316.
Kimbrell, A. (ed.) 2002, Fatal Harvest: The Tragedy of Industrial Agriculture, Island Press, Washington.
Kimbrell, A. (ed.) 2003, Fatal Harvest: The Tragedy of Industrial Agriculture, Foundation for Deep Ecology, New York.
Kongshaug, G. 1998, European Fertilizer Manufacturers Association, EFMA Seminar, Prague.
Larson, W. E. 1979, Crop residue: Energy production or erosion control?, J. Soil & Water Conservation 34(2): 74–76.
Lide, D. R. (ed.) 1994, CRC Handbook of Chemistry and Physics, CRC Press, Boca Raton, FL, 75 edition.
Lindstrom, M. J., C., G. S., Onstad, C. A., Larson, W. E., and Holt, R. E. 1979, Tillage and crop residue effects on soil erosion in the Corn Belt, J. Soil & Water Conservation 34(2): 80–82.
Maiorella, B. 1985, Comprehensive Biotechnology, Vol. 3, Chapt. Ethanol, Pergamon Press.
Marland, G., Boden, T. A., and Andres, R. J. 2004, Carbon Dioxide Information Analysis Center, U.S. Department of Energy, Oak Ridge National Laboratory, https://cdiac.esd.ornl.gov/trends/emis/em−cont.htm.
Maxwell, J. C. 2001, Theory of Heat, Dover, New York, 9th edition.
Michaud, A. 1995, in Auberge des Seigneurs Saint-Hyacinthe, Conseil des productions v´eg´etales du Qu´ebec, pp 89–113.
Miller, D. F. 1958, Composition of Cereal Grains and Forages, National Academy of Sciences National Research Council, Washington, D. C..
Mudahar, M. S. and Hignett, T. P. 1982, Handbook of energy in world agriculture, pp 50–94, Elsevier, Essex.
NASS 2002, National Agricultural Chemical Usage – 2001 Field Crops Summary, National Agricultural Statistics Service (NASS), Agricultural Statistics Board, U.S. Department of Agriculture: https://usda.mannlib.cornell.edu/reports/nassr/other/pcu-bb/% -agcs0502.pdf.
NASS 2004a, Crop Production – 2003 Summary, National Agricultural Statistics Service (NASS), Agricultural Statistics Board, U.S. Department of Agriculture: https://usda.mannlib.cornell.edu/reports/nassr/field/pcp-bban/cropan04.pdf.
NASS 2004b, National Agricultural Chemical Usage – Historic Data, National Agricultural Statistics
Service (NASS), Agricultural Statistics Board, U.S. Department of Agriculture: https://www.usda.gov/nass/pubs/dataprd1.htm.
Nielsen, R. L. 2002, Corn Yield Trends for Indiana 1930 – 2001, Agronomy Dept., Purdue Univ.:
https://www.agry.purdue.edu/ext/corn/news/CornYldTrend01.html.
NRC 1999, Ozone-Forming Potential of Reformulated Gasoline, National Academy Press, Washington, D.C., National Research Council Committee.
NREL 2002, Life Cycle Analysis – Corn Stover vs Petroleum in Iowa, National Renewable Energy Laboratory, U.S. Department of Energy: https://www.nrel.gov/docs/gen/fy02/31792.pdf.
Patyk, A. and Reinhardt, G. A. 1997, D¨ungemittel – Energie – und Strombilanzen, Vieweg-Verlag, Wiesbaden.
Patzek, T. W. 2004, Thermodynamics of the corn-ethanol biofuel cycle, Critical Reviews in Plant Sciences 23(6): 519–567, An updated web version is at https://petroleum.berkeley.edu/papers/-patzek/CRPS416-Patzek-Web.pdf
Patzek, T. W. 2006, Letter, Science 312: 1747.
Patzek, T. W., Anti, S.-M., Campos, R., Ha, K. W., Lee, J., Li, B., Padnick, J., and Yee, S.-A. 2005, Ethanol from corn: Clean renewable fuel for the future, or drain on our resources and pockets?, Environment, Development & Sustainability 7: 319 – 336.
Patzek, T.W. and Pimentel, D. 2006, Thermodynamics of energy production from biomass, Critical Reviews in Plant Sciences 24(5–6): 329–364, Available at https://petroleum.berkeley.edu/papers/patzek/CRPS-BiomassPaper.pdf.
Pimentel, D. 1990, Handbook of Energy Utilization in Agriculture, CRC Press, Boc Raton, FL..
Pimentel, D. 1991, Ethanol fuels: Energy security, economics, and the environment, Journal of Agricultural and Environmental Ethics 4: 1–13.
Pimentel, D. 1996, Food, Energy, and Society, University Press of Colorado, Niwot, CO.
Pimentel, D. 2001, Encyclopedia of Physical Science and Technology, Chapt. The limits of biomass energy, Academic Press, New York, 3 edition.
Pimentel, D. 2003, Ethanol fuels: Energy balance, economics, and environmental impacts are negative, Natural Resources and Research 12(2): 127–134.
Pimentel, D. 2004a, Private Communication, Cornell University.
Pimentel, D. 2004b, Private Communication, Cornell University.
Pimentel, D. 2004c, Private Communication, Cornell University.
Pimentel, D. 2006, Soil erosion: A food and environment threat, Environment, Development & Sustainability 8: 119–137.
Pimentel, D. and Dazhong, W. 1990, Agroecology, Chapt. Technological changes in energy use in U.S. agricultural production, pp 147–164, McGraw Hill, New York.
Pimentel, D., Herdendorf, S., Eisenfeld, S., Olander, L., Corroquino, M., Corson, C., McDade, J., Chung, Y., Cannon, W., Roberts, J., Bluman, L., and Gregg, J. 1994, Achieving a secure energy future: environmental and economic issues, Ecological Economics 9(3): 201–219.
Pimentel, D., Warneke, A. F., Teel, W. S., Schwab, K. A., Simcox, N. J., Ebert, D. M., Baenisch, K. D., and Aaron, M. R. 1988, Food versus biomass fuel: Socioeconomic and environmental impacts in the United States, Brazil, India, and Kenya, Advances in Food Research 32: 185–238.
Planck, M. 1926, Treatise on Thermodynamics, Dover Publications, Inc., New York, 3 edition, 1945 Dover Reproduction.
Pollan, M. 2002, Industrial Corn – Destroying Our Health & Environment, New York Times, July 18th, Op Ed.
Rice, D. W. et al. 1999, Health and Environmental Assessment of the Use of Ethanol as a Fuel Oxygenate – Report to the California Environmental Policy Council in Response to Executive Order D-5-99, UCRL-AR-135949, Air Resources Board, Lawrence Livermore National Laboratory, CA.
Riekert, L. 1975, Energy transformation through chemical processes (in German), Chem. Ing. Tech. 47: 48–51.
Rogner, H. H. 2000, World Energy Assessment, Chapt. Energy Resources, pp 135–171, United Nations Development Programme, New York, USA.
Rosenberg, N. J., Epstein, D. J., Wang, D., Vail, L., Srinivasan, R., and Arnold, J. G. 1999, Possible impacts of global warming on the hydrology of the Ogallala aquifer, Climatic Change 42: 677–692.
R¨ubbelke, D. 1998, Entropic limits of irreversible processes and possible adaptation mechanisms for sustainable development, World Resource Review 10(2): 186–205.
Schneider, B. H. and Spraque, G. F. 1955, Corn and Corn Improvement, Academic Press, New York.
Schr¨odinger, E. 1967, What is Life? The physical aspects of the living cell, Cambridge University Press, Cambridge, U.K..
Shapouri, H., Duffield, J. A., and Wang, M. 2002a, The Energy Balance of Corn Ethanol: An Update, Agricultural Economic Report No. 814, U.S. Department of Agriculture, Economic Research Service, Office of the Chief Economist, Office of Energy Policy and New Uses, Washington, D.C..
Shapouri, H., Gallagher, P., and Graboski, M. S. 2002b, USDA’s 1998 Ethanol Cost-of-Production Survey, Agricultural Economic Report No. 808, U.S. Department of Agriculture, Economic Research Service, Office of Energy and New Uses, Washington, D.C..
Sheehan, J., Aden, A., Paustian, K., Killian, K., Brenner, J., Walsh, M., and Nelson, R. 2004, Energy and environmental aspects of using corn stover for fuel ethanol, J. Ind. Ecology 7(3-4): 117–146.
Sheehan, J., Camobreco, V., Duffield, J., Graboski, M., and Shapouri, H. 1998, Life Cycle Inventory of Biodiesel and Petroleum Diesel for Use in an Urban Bus, Final Report NREL/SR-580-24089, National Renewable Energy Laboratory, Golden, Colorado 80401, www.nrel.gov/docs/legosti/fy98/24089.pdf.
Smil, V. 1985, Carbon – Nitrogen – Sulfur – Human Interferences in Grand Biospheric Cycles,Plenum Press, New York and London.
Spiers, H. M. 1961, Technical Data on Fuel, The British National Committee, World Power Conference, 201 Grand Buildings, Trafalgar Square, London WC2, 6 edition.
Stahl, A. 1996, Entropiebilanzen und Ressourcenverbrauch, Naturwissenschaften 83: 459–466.
Stevenson, F. J. 1982, Humus chemistry. Genesis, composition, reactions, John Wiley & Sons, New York.
Stodola, A. 1898, The cyclic processes of the gas engine (in German), Zeitschrift des Vereines Deutscher Ingenieure (Z. VDI) 32(38): 1086–1091.
Stodola, A. 1927, Steam and Gas Turbines with the Supplement on the prospects of the thermal prime mover, McGraw-Hill Book Company, Ltd., New York, 1 edition, Two volumes, authorized translation of the sixth German edition.
Szargut, J., Morris, D. R., and Steward, F. R. 1988, Exergy analysis of thermal and metallurgical processes, Hemisphere Publishing Corporation, New York.
Termuehlen, H. and Emsperger, W. 2003, Clean and Efficient Coal-fired Power Plants – Development toward advanced technologies, ASME Press, New York.
Tisdale, S. L., Nelson, W. L., and Beaton, J. D. (eds.) 1985, Soil Fertility and Fertilizers, Macmillan, New York.
Troeh, F. R. and Thompson, L. M. 1993, Soils and Soil Fertility, Oxford University Press, New York.
Tromp, T. K., Shia, R.-L., Allen, M., Eiler, J. M., and Yung, Y. L. 2003, Potential environmental impact of a hydrogen economy on the stratosphere, Science 300: 1740–1742.
USDA 1998, Farm and Ranch Irrigation Survey, 1998, National Agricultural Statistics Service (NASS), Agricultural Statistics Board, U.S. Department of Agriculture: 1997 Census of Agriculture. v. 3, Special Studies, https://www.nass.usda.gov/census/census97/fris/fris.htm.
USGS 2003, Water-level changes 1980-1997, and saturated thickness, 1996-97, in the High Plains Aquifer, U.S. Geological Survey, https://water.usgs.gov/pubs/FS078-03.
Wall, G. 1997, Thermodynamic Analysis and Improvement of Energy Systems, Proceedings of the International Conference on Thermodynamic Analysis and Improvement of Energy Systems: Exergy use in the Swedish society 1994, pp 403–413, Chinese Society of Engineering Thermophysics and American Society of Mechanical Engineers, Beijing, China.
Wang, M., Saricks, C., and Wu, M. 1997, Fuel-cycle fossil energy use and greenhouse gas emissions of fuel ethanol produced from U.S. Midwest corn, Report sponsored by the Illinois Department of Commerce and Community Affairs, Argonne National Laboratory, Center for Transportation Research, Argonne, IL 60439.
Webster 1993, Webster’s Third New International Dictionary of the English Language – Unabridged, Encyclopædia Britannica, Inc., Chicago.
Wheaton, H. N., Martz, F., Meinershagen, F., and Sewell, H. 1993, Corn Silage, Department of Agronomy, University of Missouri-Columbia: https://muextension.missouri.edu/explore/agguides/crops/g04590.htm.
White, P. J. and Johnson, L. A. (eds.) 2003, Corn Chemistry and Technology, American Association of Cereal Chemists.
Worrell, E., Meuleman, B., and Blok, K. 1995, Energy savings by efficient application of fertilizer, Resources, Conservation, Recycling 13: 233–250.
Worrell, E., Pylipsen, D., and Martin, N. 2000, Energy use and energy intensity of the U.S.chemical industry, Report LBNL-44314, Energy Analysis Department, Environmental Energy Technologies Division, LBNL, Berkeley, CA 94720.
Worrell, E., van Heijningen, R. J. J., de Castro, J. F. M., Hazeewinkel, J. H. O., de Beer, J. G., Fauu, A. P. C., and Vringer, K. 1994, New gross energy-requirement figures for materials production, Energy 19: 627–640.
Wright, F. B. 1994, Distillation of alcohol and de-naturing, Lindsay Publications, Bradley, IL, 2nd edition.
Young, S. and Vanderburg, W. H. 1994, Applying environmental life-cycle analysis to materials, JOM 46(4): 22 – 27.
Part VI
Tables
